YASS results
/ uc5 / uc5-edfs-n21-rf3
uc5-edfs-n21-rf3
edfs
Failed
Parameters
| parameter | value | unit | description |
|---|---|---|---|
| engine | edfs | — | Storage/transport engine under test (edfs or tus) |
| sat_count | 21 | sats | Number of satellites in the constellation |
| RF | 3 | copies | EDFS replication factor (n/a for TUS) |
KPIs
| KPI | value | unit | description |
|---|---|---|---|
| state | Success | — | Terminal experiment state (Success/TimedOut/Failure) |
| exec_date | 2026-06-08 08:30 UTC | UTC | Wall-clock date/time the experiment was launched (CR creationTimestamp) |
| duration | 16m 1s | — | Experiment duration on the simulation clock (simulationStartTime → experimentTime) |
| sim_start | 2026-05-16 23:59 UTC | UTC | Simulation clock at experiment start (simulationStartTime) |
| sim_end | 2026-05-17 00:15 UTC | UTC | Simulation clock when the experiment finished (experimentTime) |
| produced | 16 | files | Files produced by the producer agent(s) |
| files_to_GS | 4 | count | Distinct produced files that reached at least one ground station |
| delivery_success_rate | 80 | % | Distinct files reaching ≥1 GS as a percentage of files produced (UC2/UC5 primary KPI) |
| all_delivered | no | — | Whether every produced file reached a ground station |
| first_GS_delivery_s | 300 | s | Time from sim start until the first produced file reached any ground station |
| last_GS_delivery_s | 518 | s | Time from sim start until the last produced file reached a ground station (all-delivered time) |
| GS_reached | 7 | count | Ground stations that received the file (from received_total — independent of the delivery-time metric) |
| distinct_receivers | 27 | count | Distinct nodes that received a file (GS + relays) |
| TX_MiB | 9430 | MiB | Total network bytes transmitted, all nodes |
| peak_cpu_m | 510 | millicores | Peak CPU across all containers |
| peak_mem_MiB | 236 | MiB | Peak memory across all containers |
| notes | 12 of 16 file(s) undelivered | — | Data-quality flags for this run (missing metrics, undelivered files) |
Charts (interactive)
Node colours are consistent across every chart and the graph: ■ ground station · ■ relay satellite · ■ producer.
Per-target delivery time
Seconds from file creation until each target node held the complete file. Bars coloured by node kind; the delivery KPI is the earliest ground-station bar.
Network TX over time (MiB)
Cumulative TX summed across all nodes, vs seconds from experiment start.
CPU and memory over time
Aggregate CPU (millicores, left axis) and memory (MiB, right axis) across all containers, vs seconds from experiment start.
Network TX by node (top 20)
Total bytes transmitted per node over the run, coloured by node kind.
Peak CPU per node (top 20)
Peak CPU (millicores) reached by each fsNode during the run, coloured by node kind.
Peak memory per node (top 20)
Peak memory (MiB) reached by each fsNode during the run, coloured by node kind.
File propagation graph
■ ground station · ● relay satellite · ● producer (same colours as the charts). Spread tree: one edge
from → to per node = where it first acquired the file by the selected time. Grouped per file; 0-byte control messages omitted; times bucketed to ~2 s for cross-node clock skew. Timeline spans the whole experiment (0 = simulation start). Delivery completeness is the File deliveries table below. File transfer graph (rate)
Same nodes; edge
from → to = bytes transferred within the trailing window ending at the selected time (instantaneous flow). Edge colour = bandwidth (bits/s, blue = low → red = high); label shows the rate. Play to watch where traffic moves moment-to-moment. Timeline is the simulation clock (0 = simulation start), shared with the charts above.File deliveries
| file | received by | delivery (s from creation) | time from start | #fsNodes with file |
|---|---|---|---|---|
| oneweb-0008_1 | oneweb-0008 producer | t0 | 1m 41s from start ← t0 | 1 |
| oneweb-0008_1 | estrack-cebreros GS | t0 + 11.9s | 1m 53s from start | 2 |
| oneweb-0008_1 | estrack-kiruna GS | t0 + 12.0s | 1m 53s from start | 3 |
| oneweb-0008_1 | estrack-new-norcia GS | t0 + 12.2s | 1m 54s from start | 4 |
| oneweb-0008_1 | estrack-kourou GS | t0 + 12.2s | 1m 54s from start | 5 |
| oneweb-0008_1 | estrack-redu GS | t0 + 12.2s | 1m 54s from start | 6 |
| oneweb-0008_1 | estrack-malargue GS | t0 + 12.3s | 1m 54s from start | 7 |
| oneweb-0008_1 | oneweb-0020 | t0 + 14.9s | 1m 56s from start | 8 |
| oneweb-0008_1 | oneweb-0024 | t0 + 14.9s | 1m 56s from start | 9 |
| oneweb-0008_1 | oneweb-0025 | t0 + 15.5s | 1m 57s from start | 10 |
| oneweb-0008_1 | oneweb-0037 | t0 + 15.9s | 1m 57s from start | 11 |
| oneweb-0008_1 | estrack-santa-maria GS | t0 + 19.1s | 2m 1s from start | 12 |
| oneweb-0008_1 | oneweb-0029 | t0 + 19.5s | 2m 1s from start | 13 |
| oneweb-0008_1 | oneweb-0038 | t0 + 31.0s | 2m 12s from start | 14 |
| oneweb-0008_1 | oneweb-0031 | t0 + 50.5s | 2m 32s from start | 15 |
| oneweb-0008_1 | oneweb-0021 | t0 + 54.7s | 2m 36s from start | 16 |
| oneweb-0008_1 | oneweb-0007 | t0 + 57.6s | 2m 39s from start | 17 |
| oneweb-0008_2 | oneweb-0008 producer | t0 | 3m 43s from start ← t0 | 1 |
| oneweb-0008_2 | oneweb-0020 | t0 + 30.6s | 4m 14s from start | 2 |
| oneweb-0008_2 | oneweb-0025 | t0 + 30.9s | 4m 14s from start | 3 |
| oneweb-0008_2 | oneweb-0029 | t0 + 31.3s | 4m 14s from start | 4 |
| oneweb-0008_2 | oneweb-0024 | t0 + 31.6s | 4m 15s from start | 5 |
| oneweb-0008_2 | oneweb-0038 | t0 + 35.2s | 4m 18s from start | 6 |
| oneweb-0008_2 | oneweb-0007 | t0 + 47.9s | 4m 31s from start | 7 |
| oneweb-0008_2 | oneweb-0031 | t0 + 67.3s | 4m 50s from start | 8 |
| oneweb-0008_2 | oneweb-0021 | t0 + 67.8s | 4m 51s from start | 9 |
| oneweb-0008_2 | estrack-kourou GS | t0 + 587.6s | 13m 31s from start | 10 |
| oneweb-0008_2 | estrack-new-norcia GS | t0 + 587.9s | 13m 31s from start | 11 |
| oneweb-0008_2 | estrack-malargue GS | t0 + 587.9s | 13m 31s from start | 12 |
| oneweb-0008_2 | estrack-cebreros GS | t0 + 656.6s | 14m 40s from start | 13 |
| oneweb-0008_2 | estrack-santa-maria GS | t0 + 658.3s | 14m 41s from start | 14 |
| oneweb-0008_2 | estrack-redu GS | t0 + 666.0s | 14m 49s from start | 15 |
| oneweb-0008_3 | oneweb-0008 producer | t0 | 5m 43s from start ← t0 | 1 |
| oneweb-0008_3 | oneweb-0038 | t0 + 56.4s | 6m 39s from start | 2 |
| oneweb-0008_3 | oneweb-0029 | t0 + 58.1s | 6m 41s from start | 3 |
| oneweb-0008_3 | oneweb-0037 | t0 + 58.1s | 6m 41s from start | 4 |
| oneweb-0008_3 | oneweb-0020 | t0 + 58.2s | 6m 41s from start | 5 |
| oneweb-0008_3 | oneweb-0025 | t0 + 58.3s | 6m 41s from start | 6 |
| oneweb-0008_3 | oneweb-0024 | t0 + 58.4s | 6m 41s from start | 7 |
| oneweb-0008_3 | oneweb-0031 | t0 + 58.5s | 6m 41s from start | 8 |
| oneweb-0008_3 | oneweb-0021 | t0 + 59.6s | 6m 42s from start | 9 |
| oneweb-0008_3 | oneweb-0007 | t0 + 59.8s | 6m 42s from start | 10 |
| oneweb-0008_3 | estrack-new-norcia GS | t0 + 529.3s | 14m 32s from start | 11 |
| oneweb-0008_3 | estrack-kiruna GS | t0 + 537.0s | 14m 40s from start | 12 |
| oneweb-0008_3 | estrack-cebreros GS | t0 + 539.9s | 14m 43s from start | 13 |
| oneweb-0008_3 | estrack-santa-maria GS | t0 + 540.7s | 14m 43s from start | 14 |
| oneweb-0008_3 | estrack-redu GS | t0 + 541.0s | 14m 44s from start | 15 |
| oneweb-0008_4 | oneweb-0008 producer | t0 | 7m 44s from start ← t0 | 1 |
| oneweb-0008_4 | oneweb-0037 | t0 + 33.7s | 8m 18s from start | 2 |
| oneweb-0008_4 | oneweb-0020 | t0 + 37.5s | 8m 22s from start | 3 |
| oneweb-0008_4 | oneweb-0029 | t0 + 38.6s | 8m 23s from start | 4 |
| oneweb-0008_4 | oneweb-0025 | t0 + 40.7s | 8m 25s from start | 5 |
| oneweb-0008_4 | oneweb-0024 | t0 + 41.2s | 8m 25s from start | 6 |
| oneweb-0008_4 | oneweb-0007 | t0 + 43.5s | 8m 28s from start | 7 |
| oneweb-0008_4 | estrack-kiruna GS | t0 + 411.9s | 14m 36s from start | 8 |
| oneweb-0008_4 | estrack-new-norcia GS | t0 + 413.0s | 14m 37s from start | 9 |
| oneweb-0008_4 | estrack-cebreros GS | t0 + 421.4s | 14m 45s from start | 10 |
| oneweb-0008_4 | estrack-redu GS | t0 + 421.4s | 14m 45s from start | 11 |
| oneweb-0008_4 | estrack-santa-maria GS | t0 + 423.2s | 14m 47s from start | 12 |
| oneweb-0008_4 | estrack-kourou GS | t0 + 424.8s | 14m 49s from start | 13 |
| oneweb-0013_2 | oneweb-0013 producer | t0 | 3m 41s from start ← t0 | 1 |
| oneweb-0013_2 | oneweb-0023 | t0 + 15.6s | 3m 57s from start | 2 |
| oneweb-0013_2 | oneweb-0010 | t0 + 21.4s | 4m 3s from start | 3 |
| oneweb-0013_2 | oneweb-0028 | t0 + 25.4s | 4m 7s from start | 4 |
| oneweb-0013_2 | oneweb-0017 | t0 + 28.0s | 4m 9s from start | 5 |
| oneweb-0013_2 | oneweb-0011 | t0 + 29.0s | 4m 10s from start | 6 |
| oneweb-0013_2 | oneweb-0021 | t0 + 59.6s | 4m 41s from start | 7 |
| oneweb-0013_2 | oneweb-0031 | t0 + 65.1s | 4m 46s from start | 8 |
| oneweb-0013_2 | estrack-redu GS | t0 + 590.5s | 13m 32s from start | 9 |
| oneweb-0013_2 | estrack-new-norcia GS | t0 + 590.6s | 13m 32s from start | 10 |
| oneweb-0013_2 | estrack-malargue GS | t0 + 590.6s | 13m 32s from start | 11 |
| oneweb-0013_2 | estrack-kourou GS | t0 + 591.0s | 13m 32s from start | 12 |
| oneweb-0013_2 | estrack-santa-maria GS | t0 + 592.5s | 13m 34s from start | 13 |
| oneweb-0013_2 | estrack-cebreros GS | t0 + 596.8s | 13m 38s from start | 14 |
| oneweb-0013_3 | oneweb-0013 producer | t0 | 5m 42s from start ← t0 | 1 |
| oneweb-0013_3 | oneweb-0023 | t0 + 16.6s | 5m 59s from start | 2 |
| oneweb-0013_3 | oneweb-0011 | t0 + 18.5s | 6m 1s from start | 3 |
| oneweb-0013_3 | oneweb-0017 | t0 + 26.1s | 6m 8s from start | 4 |
| oneweb-0013_3 | oneweb-0028 | t0 + 26.7s | 6m 9s from start | 5 |
| oneweb-0013_3 | oneweb-0010 | t0 + 30.5s | 6m 13s from start | 6 |
| oneweb-0013_3 | oneweb-0021 | t0 + 54.4s | 6m 37s from start | 7 |
| oneweb-0013_3 | oneweb-0031 | t0 + 63.9s | 6m 46s from start | 8 |
| oneweb-0013_3 | estrack-redu GS | t0 + 504.7s | 14m 7s from start | 9 |
| oneweb-0013_3 | estrack-santa-maria GS | t0 + 504.8s | 14m 7s from start | 10 |
| oneweb-0013_3 | estrack-malargue GS | t0 + 504.9s | 14m 7s from start | 11 |
| oneweb-0013_3 | estrack-new-norcia GS | t0 + 504.9s | 14m 7s from start | 12 |
| oneweb-0013_3 | estrack-cebreros GS | t0 + 505.8s | 14m 8s from start | 13 |
| oneweb-0013_3 | estrack-kiruna GS | t0 + 507.6s | 14m 10s from start | 14 |
| oneweb-0013_4 | oneweb-0013 producer | t0 | 7m 43s from start ← t0 | 1 |
| oneweb-0013_4 | oneweb-0023 | t0 + 14.9s | 7m 58s from start | 2 |
| oneweb-0013_4 | oneweb-0011 | t0 + 19.6s | 8m 3s from start | 3 |
| oneweb-0013_4 | oneweb-0017 | t0 + 27.4s | 8m 10s from start | 4 |
| oneweb-0013_4 | oneweb-0010 | t0 + 43.3s | 8m 26s from start | 5 |
| oneweb-0013_4 | oneweb-0028 | t0 + 48.6s | 8m 31s from start | 6 |
| oneweb-0013_4 | oneweb-0021 | t0 + 65.6s | 8m 49s from start | 7 |
| oneweb-0013_4 | oneweb-0031 | t0 + 69.3s | 8m 52s from start | 8 |
| oneweb-0013_4 | estrack-santa-maria GS | t0 + 396.1s | 14m 19s from start | 9 |
| oneweb-0013_4 | estrack-cebreros GS | t0 + 396.4s | 14m 19s from start | 10 |
| oneweb-0013_4 | estrack-kiruna GS | t0 + 396.6s | 14m 20s from start | 11 |
| oneweb-0013_4 | estrack-new-norcia GS | t0 + 396.8s | 14m 20s from start | 12 |
| oneweb-0013_4 | estrack-redu GS | t0 + 397.3s | 14m 20s from start | 13 |
| oneweb-0013_6 | oneweb-0013 producer | t0 | 11m 44s from start ← t0 | 1 |
| oneweb-0013_6 | oneweb-0023 | t0 + 14.6s | 11m 58s from start | 2 |
| oneweb-0013_6 | oneweb-0028 | t0 + 20.4s | 12m 4s from start | 3 |
| oneweb-0013_6 | oneweb-0017 | t0 + 26.5s | 12m 10s from start | 4 |
| oneweb-0013_6 | oneweb-0011 | t0 + 31.5s | 12m 15s from start | 5 |
| oneweb-0013_6 | oneweb-0008 | t0 + 58.2s | 12m 42s from start | 6 |
| oneweb-0013_6 | oneweb-0031 | t0 + 63.2s | 12m 47s from start | 7 |
| oneweb-0013_6 | estrack-kiruna GS | t0 + 164.4s | 14m 28s from start | 8 |
| oneweb-0013_6 | estrack-redu GS | t0 + 168.2s | 14m 32s from start | 9 |
| oneweb-0013_6 | estrack-santa-maria GS | t0 + 170.0s | 14m 34s from start | 10 |
| oneweb-0013_6 | estrack-cebreros GS | t0 + 172.2s | 14m 36s from start | 11 |
| oneweb-0013_6 | estrack-new-norcia GS | t0 + 177.8s | 14m 42s from start | 12 |
| oneweb-0013_6 | estrack-kourou GS | t0 + 185.6s | 14m 49s from start | 13 |
| oneweb-0018_1 | oneweb-0018 producer | t0 | 1m 40s from start ← t0 | 1 |
| oneweb-0018_1 | oneweb-0027 | t0 + 50.9s | 2m 31s from start | 2 |
| oneweb-0018_1 | oneweb-0012 | t0 + 51.6s | 2m 32s from start | 3 |
| oneweb-0018_1 | estrack-santa-maria GS | t0 + 693.5s | 13m 14s from start | 4 |
| oneweb-0018_1 | estrack-new-norcia GS | t0 + 693.5s | 13m 14s from start | 5 |
| oneweb-0018_1 | estrack-cebreros GS | t0 + 693.6s | 13m 14s from start | 6 |
| oneweb-0018_1 | estrack-malargue GS | t0 + 693.6s | 13m 14s from start | 7 |
| oneweb-0018_1 | estrack-redu GS | t0 + 693.7s | 13m 14s from start | 8 |
| oneweb-0018_1 | estrack-kourou GS | t0 + 693.9s | 13m 14s from start | 9 |
| oneweb-0018_2 | oneweb-0018 producer | t0 | 3m 41s from start ← t0 | 1 |
| oneweb-0018_2 | oneweb-0027 | t0 + 54.2s | 4m 35s from start | 2 |
| oneweb-0018_2 | oneweb-0012 | t0 + 56.6s | 4m 38s from start | 3 |
| oneweb-0018_2 | estrack-malargue GS | t0 + 612.7s | 13m 54s from start | 4 |
| oneweb-0018_2 | estrack-new-norcia GS | t0 + 612.7s | 13m 54s from start | 5 |
| oneweb-0018_2 | estrack-cebreros GS | t0 + 612.8s | 13m 54s from start | 6 |
| oneweb-0018_2 | estrack-kiruna GS | t0 + 612.8s | 13m 54s from start | 7 |
| oneweb-0018_2 | estrack-santa-maria GS | t0 + 612.9s | 13m 54s from start | 8 |
| oneweb-0018_2 | estrack-redu GS | t0 + 613.0s | 13m 54s from start | 9 |
| oneweb-0018_3 | oneweb-0018 producer | t0 | 5m 43s from start ← t0 | 1 |
| oneweb-0018_3 | oneweb-0027 | t0 + 59.2s | 6m 42s from start | 2 |
| oneweb-0018_3 | oneweb-0012 | t0 + 160.8s | 8m 23s from start | 3 |
| oneweb-0018_3 | oneweb-0010 | t0 + 183.8s | 8m 46s from start | 4 |
| oneweb-0018_3 | estrack-new-norcia GS | t0 + 518.5s | 14m 21s from start | 5 |
| oneweb-0018_3 | estrack-santa-maria GS | t0 + 518.5s | 14m 21s from start | 6 |
| oneweb-0018_3 | estrack-redu GS | t0 + 518.7s | 14m 21s from start | 7 |
| oneweb-0018_3 | estrack-cebreros GS | t0 + 518.8s | 14m 21s from start | 8 |
| oneweb-0018_3 | estrack-kiruna GS | t0 + 519.1s | 14m 22s from start | 9 |
| oneweb-0018_4 | oneweb-0018 producer | t0 | 7m 43s from start ← t0 | 1 |
| oneweb-0018_4 | oneweb-0027 | t0 + 119.3s | 9m 42s from start | 2 |
| oneweb-0018_4 | oneweb-0010 | t0 + 142.9s | 10m 6s from start | 3 |
| oneweb-0018_4 | estrack-cebreros GS | t0 + 423.3s | 14m 46s from start | 4 |
| oneweb-0018_4 | estrack-new-norcia GS | t0 + 423.3s | 14m 46s from start | 5 |
| oneweb-0018_4 | estrack-kiruna GS | t0 + 423.4s | 14m 46s from start | 6 |
| oneweb-0018_4 | estrack-malargue GS | t0 + 423.4s | 14m 46s from start | 7 |
| oneweb-0018_4 | estrack-santa-maria GS | t0 + 423.5s | 14m 46s from start | 8 |
| oneweb-0018_4 | estrack-kourou GS | t0 + 423.7s | 14m 46s from start | 9 |
| oneweb-0018_4 | estrack-redu GS | t0 + 423.8s | 14m 47s from start | 10 |
| oneweb-0027_1 | oneweb-0027 producer | t0 | 1m 40s from start ← t0 | 1 |
| oneweb-0027_1 | oneweb-0012 | t0 + 11.6s | 1m 52s from start | 2 |
| oneweb-0027_1 | oneweb-0018 | t0 + 62.2s | 2m 42s from start | 3 |
| oneweb-0027_1 | oneweb-0026 | t0 + 65.8s | 2m 46s from start | 4 |
| oneweb-0027_1 | oneweb-0006 | t0 + 86.3s | 3m 7s from start | 5 |
| oneweb-0027_1 | estrack-malargue GS | t0 + 698.6s | 13m 19s from start | 6 |
| oneweb-0027_1 | estrack-santa-maria GS | t0 + 698.7s | 13m 19s from start | 7 |
| oneweb-0027_1 | estrack-redu GS | t0 + 698.7s | 13m 19s from start | 8 |
| oneweb-0027_1 | estrack-cebreros GS | t0 + 698.8s | 13m 19s from start | 9 |
| oneweb-0027_1 | estrack-kourou GS | t0 + 698.8s | 13m 19s from start | 10 |
| oneweb-0027_1 | estrack-new-norcia GS | t0 + 698.9s | 13m 19s from start | 11 |
| oneweb-0027_2 | oneweb-0027 producer | t0 | 3m 41s from start ← t0 | 1 |
| oneweb-0027_2 | oneweb-0012 | t0 + 31.6s | 4m 13s from start | 2 |
| oneweb-0027_2 | oneweb-0026 | t0 + 36.4s | 4m 17s from start | 3 |
| oneweb-0027_2 | oneweb-0018 | t0 + 56.6s | 4m 38s from start | 4 |
| oneweb-0027_2 | estrack-new-norcia GS | t0 + 582.7s | 13m 24s from start | 5 |
| oneweb-0027_2 | estrack-santa-maria GS | t0 + 582.8s | 13m 24s from start | 6 |
| oneweb-0027_2 | estrack-cebreros GS | t0 + 582.9s | 13m 24s from start | 7 |
| oneweb-0027_2 | estrack-malargue GS | t0 + 582.9s | 13m 24s from start | 8 |
| oneweb-0027_2 | estrack-redu GS | t0 + 582.9s | 13m 24s from start | 9 |
| oneweb-0027_2 | estrack-kourou GS | t0 + 583.0s | 13m 24s from start | 10 |
| oneweb-0027_3 | oneweb-0027 producer | t0 | 5m 42s from start ← t0 | 1 |
| oneweb-0027_3 | oneweb-0018 | t0 + 55.9s | 6m 38s from start | 2 |
| oneweb-0027_3 | oneweb-0026 | t0 + 88.9s | 7m 11s from start | 3 |
| oneweb-0027_3 | estrack-new-norcia GS | t0 + 515.1s | 14m 17s from start | 4 |
| oneweb-0027_3 | estrack-kiruna GS | t0 + 515.1s | 14m 17s from start | 5 |
| oneweb-0027_3 | estrack-santa-maria GS | t0 + 515.4s | 14m 17s from start | 6 |
| oneweb-0027_3 | estrack-redu GS | t0 + 515.4s | 14m 17s from start | 7 |
| oneweb-0027_3 | estrack-cebreros GS | t0 + 515.6s | 14m 17s from start | 8 |
| oneweb-0027_4 | oneweb-0027 producer | t0 | 7m 42s from start ← t0 | 1 |
| oneweb-0027_4 | oneweb-0026 | t0 + 131.1s | 9m 53s from start | 2 |
| oneweb-0027_4 | oneweb-0012 | t0 + 133.2s | 9m 55s from start | 3 |
| oneweb-0027_4 | oneweb-0018 | t0 + 138.1s | 10m 0s from start | 4 |
| oneweb-0027_4 | estrack-new-norcia GS | t0 + 431.5s | 14m 54s from start | 5 |
| oneweb-0027_4 | estrack-cebreros GS | t0 + 431.8s | 14m 54s from start | 6 |
| oneweb-0027_4 | estrack-kiruna GS | t0 + 431.8s | 14m 54s from start | 7 |
| oneweb-0027_4 | estrack-santa-maria GS | t0 + 431.9s | 14m 54s from start | 8 |
| oneweb-0027_4 | estrack-malargue GS | t0 + 431.9s | 14m 54s from start | 9 |
| oneweb-0027_4 | estrack-kourou GS | t0 + 432.2s | 14m 54s from start | 10 |
Charts
charts/network_tx.png
gnuplot/delivery.png
Files
- Kubernetes resources — manifests to reproduce this run (hardwaredefinitions, layout, experimentdefinition, experiment)
- metrics.json — KPIs as JSON
- raw-parquet.tar — raw metrics & events as typed, zstd-compressed Parquet (one file per series; read with pandas/polars/DuckDB)
