YASS results
/ uc2 / uc2-edfs-plow-n100-rf3
uc2-edfs-plow-n100-rf3
edfs
Failed
Parameters
| parameter | value | unit | description |
|---|---|---|---|
| engine | edfs | — | Storage/transport engine under test (edfs or tus) |
| priority | low | — | File priority class (low/default/high; EDFS PAR) |
| sat_count | 100 | sats | Number of satellites in the constellation |
| RF | 3 | copies | EDFS replication factor (n/a for TUS) |
KPIs
| KPI | value | unit | description |
|---|---|---|---|
| state | TimedOut | — | Terminal experiment state (Success/TimedOut/Failure) |
| exec_date | 2026-06-09 00:20 UTC | UTC | Wall-clock date/time the experiment was launched (CR creationTimestamp) |
| duration | 5h 59m 56s | — | Experiment duration on the simulation clock (simulationStartTime → experimentTime) |
| sim_start | 2026-05-16 23:59 UTC | UTC | Simulation clock at experiment start (simulationStartTime) |
| sim_end | 2026-05-17 05:58 UTC | UTC | Simulation clock when the experiment finished (experimentTime) |
| produced | 100 | files | Files produced by the producer agent(s) |
| files_to_GS | 16 | count | Distinct produced files that reached at least one ground station |
| delivery_success_rate | 16 | % | Distinct files reaching ≥1 GS as a percentage of files produced (UC2/UC5 primary KPI) |
| all_delivered | no | — | Whether every produced file reached a ground station |
| first_GS_delivery_s | 23 | s | Time from sim start until the first produced file reached any ground station |
| last_GS_delivery_s | 21076 | s | Time from sim start until the last produced file reached a ground station (all-delivered time) |
| GS_reached | 6 | count | Ground stations that received the file (from received_total — independent of the delivery-time metric) |
| distinct_receivers | 6 | count | Distinct nodes that received a file (GS + relays) |
| TX_MiB | 183851 | MiB | Total network bytes transmitted, all nodes |
| peak_cpu_m | 1080 | millicores | Peak CPU across all containers |
| peak_mem_MiB | 185 | MiB | Peak memory across all containers |
| notes | 84 of 100 file(s) undelivered | — | Data-quality flags for this run (missing metrics, undelivered files) |
Charts (interactive)
Node colours are consistent across every chart and the graph: ■ ground station · ■ relay satellite · ■ producer.
Per-target delivery time
Seconds from file creation until each target node held the complete file. Bars coloured by node kind; the delivery KPI is the earliest ground-station bar.
Network TX over time (MiB)
Cumulative TX summed across all nodes, vs seconds from experiment start.
CPU and memory over time
Aggregate CPU (millicores, left axis) and memory (MiB, right axis) across all containers, vs seconds from experiment start.
Network TX by node (top 20)
Total bytes transmitted per node over the run, coloured by node kind.
Peak CPU per node (top 20)
Peak CPU (millicores) reached by each fsNode during the run, coloured by node kind.
Peak memory per node (top 20)
Peak memory (MiB) reached by each fsNode during the run, coloured by node kind.
File propagation graph
■ ground station · ● relay satellite · ● producer (same colours as the charts). Spread tree: one edge
from → to per node = where it first acquired the file by the selected time. Grouped per file; 0-byte control messages omitted; times bucketed to ~2 s for cross-node clock skew. Timeline spans the whole experiment (0 = simulation start). Delivery completeness is the File deliveries table below. File transfer graph (rate)
Same nodes; edge
from → to = bytes transferred within the trailing window ending at the selected time (instantaneous flow). Edge colour = bandwidth (bits/s, blue = low → red = high); label shows the rate. Play to watch where traffic moves moment-to-moment. Timeline is the simulation clock (0 = simulation start), shared with the charts above.File deliveries
| file | received by | delivery (s from creation) | time from start | #fsNodes with file |
|---|---|---|---|---|
| oneweb-0026_0 | oneweb-0026 producer | t0 | 11s from start ← t0 | 1 |
| oneweb-0026_0 | estrack-malargue GS | t0 + 13289.1s | 3h 41m 40s from start | 2 |
| oneweb-0026_0 | estrack-kiruna GS | t0 + 17096.1s | 4h 45m 7s from start | 3 |
| oneweb-0029_0 | oneweb-0029 producer | t0 | 10s from start ← t0 | 1 |
| oneweb-0029_0 | estrack-santa-maria GS | t0 + 23.2s | 33s from start | 2 |
| oneweb-0029_0 | estrack-cebreros GS | t0 + 111.3s | 2m 1s from start | 3 |
| oneweb-0029_0 | estrack-kourou GS | t0 + 627.4s | 10m 38s from start | 4 |
| oneweb-0029_0 | estrack-new-norcia GS | t0 + 3284.1s | 54m 55s from start | 5 |
| oneweb-0029_0 | estrack-kiruna GS | t0 + 5838.6s | 1h 37m 30s from start | 6 |
| oneweb-0029_0 | estrack-malargue GS | t0 + 7736.0s | 2h 9m 7s from start | 7 |
| oneweb-0035_0 | oneweb-0035 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0035_0 | estrack-kiruna GS | t0 + 20840.2s | 5h 47m 32s from start | 2 |
| oneweb-0036_0 | oneweb-0036 producer | t0 | 11s from start ← t0 | 1 |
| oneweb-0036_0 | estrack-kiruna GS | t0 + 17723.9s | 4h 55m 35s from start | 2 |
| oneweb-0036_0 | estrack-malargue GS | t0 + 20069.5s | 5h 34m 40s from start | 3 |
| oneweb-0038_0 | oneweb-0038 producer | t0 | 11s from start ← t0 | 1 |
| oneweb-0038_0 | estrack-new-norcia GS | t0 + 2643.8s | 44m 15s from start | 2 |
| oneweb-0038_0 | estrack-kiruna GS | t0 + 5159.3s | 1h 26m 9s from start | 3 |
| oneweb-0038_0 | estrack-santa-maria GS | t0 + 5926.0s | 1h 38m 56s from start | 4 |
| oneweb-0038_0 | estrack-kourou GS | t0 + 6299.2s | 1h 45m 10s from start | 5 |
| oneweb-0038_0 | estrack-malargue GS | t0 + 7068.4s | 1h 57m 59s from start | 6 |
| oneweb-0040_0 | oneweb-0040 producer | t0 | 11s from start ← t0 | 1 |
| oneweb-0040_0 | estrack-santa-maria GS | t0 + 34.9s | 46s from start | 2 |
| oneweb-0040_0 | estrack-cebreros GS | t0 + 51.5s | 1m 2s from start | 3 |
| oneweb-0040_0 | estrack-kiruna GS | t0 + 5919.9s | 1h 38m 51s from start | 4 |
| oneweb-0040_0 | estrack-kourou GS | t0 + 7138.5s | 1h 59m 9s from start | 5 |
| oneweb-0040_0 | estrack-malargue GS | t0 + 8021.6s | 2h 13m 54s from start | 6 |
| oneweb-0040_0 | estrack-new-norcia GS | t0 + 9864.2s | 2h 44m 36s from start | 7 |
| oneweb-0045_0 | oneweb-0045 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0045_0 | estrack-malargue GS | t0 + 13277.2s | 3h 41m 30s from start | 2 |
| oneweb-0045_0 | estrack-kiruna GS | t0 + 17444.0s | 4h 50m 56s from start | 3 |
| oneweb-0051_0 | oneweb-0051 producer | t0 | 11s from start ← t0 | 1 |
| oneweb-0051_0 | estrack-new-norcia GS | t0 + 2137.2s | 35m 48s from start | 2 |
| oneweb-0051_0 | estrack-kiruna GS | t0 + 4660.3s | 1h 17m 52s from start | 3 |
| oneweb-0051_0 | estrack-santa-maria GS | t0 + 5254.1s | 1h 27m 46s from start | 4 |
| oneweb-0051_0 | estrack-kourou GS | t0 + 5707.7s | 1h 35m 18s from start | 5 |
| oneweb-0051_0 | estrack-malargue GS | t0 + 6509.6s | 1h 48m 40s from start | 6 |
| oneweb-0052_0 | oneweb-0052 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0052_0 | estrack-santa-maria GS | t0 + 3476.4s | 58m 8s from start | 2 |
| oneweb-0052_0 | estrack-new-norcia GS | t0 + 6944.0s | 1h 55m 57s from start | 3 |
| oneweb-0052_0 | estrack-kiruna GS | t0 + 9500.4s | 2h 38m 32s from start | 4 |
| oneweb-0052_0 | estrack-kourou GS | t0 + 10705.6s | 2h 58m 37s from start | 5 |
| oneweb-0052_0 | estrack-malargue GS | t0 + 11387.3s | 3h 9m 59s from start | 6 |
| oneweb-0057_0 | oneweb-0057 producer | t0 | 11s from start ← t0 | 1 |
| oneweb-0057_0 | estrack-kiruna GS | t0 + 7872.4s | 2h 11m 23s from start | 2 |
| oneweb-0057_0 | estrack-santa-maria GS | t0 + 8457.6s | 2h 21m 8s from start | 3 |
| oneweb-0057_0 | estrack-kourou GS | t0 + 8927.2s | 2h 28m 58s from start | 4 |
| oneweb-0057_0 | estrack-malargue GS | t0 + 9733.1s | 2h 42m 24s from start | 5 |
| oneweb-0057_0 | estrack-new-norcia GS | t0 + 11761.3s | 3h 16m 13s from start | 6 |
| oneweb-0058_0 | oneweb-0058 producer | t0 | 11s from start ← t0 | 1 |
| oneweb-0058_0 | estrack-kourou GS | t0 + 14632.2s | 4h 4m 3s from start | 2 |
| oneweb-0058_0 | estrack-malargue GS | t0 + 15109.5s | 4h 11m 59s from start | 3 |
| oneweb-0058_0 | estrack-new-norcia GS | t0 + 17313.8s | 4h 48m 44s from start | 4 |
| oneweb-0085_0 | oneweb-0085 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0085_0 | estrack-kiruna GS | t0 + 21075.8s | 5h 51m 28s from start | 2 |
| oneweb-0095_0 | oneweb-0095 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0095_0 | estrack-new-norcia GS | t0 + 5186.2s | 1h 26m 38s from start | 2 |
| oneweb-0095_0 | estrack-kiruna GS | t0 + 7846.8s | 2h 10m 59s from start | 3 |
| oneweb-0095_0 | estrack-kourou GS | t0 + 8979.4s | 2h 29m 51s from start | 4 |
| oneweb-0095_0 | estrack-malargue GS | t0 + 9677.4s | 2h 41m 29s from start | 5 |
| oneweb-9011_0 | oneweb-9011 producer | t0 | 13s from start ← t0 | 1 |
| oneweb-9011_0 | estrack-malargue GS | t0 + 7753.9s | 2h 9m 27s from start | 2 |
| oneweb-9011_0 | estrack-kourou GS | t0 + 8011.3s | 2h 13m 43s from start | 3 |
| oneweb-9011_0 | estrack-santa-maria GS | t0 + 8748.4s | 2h 26m 1s from start | 4 |
| oneweb-9011_0 | estrack-kiruna GS | t0 + 9582.9s | 2h 39m 56s from start | 5 |
| oneweb-9011_0 | estrack-new-norcia GS | t0 + 11771.4s | 3h 16m 24s from start | 6 |
| oneweb-9018_0 | oneweb-9018 producer | t0 | 13s from start ← t0 | 1 |
| oneweb-9018_0 | estrack-kiruna GS | t0 + 11378.4s | 3h 9m 52s from start | 2 |
| oneweb-9035_0 | oneweb-9035 producer | t0 | 10s from start ← t0 | 1 |
| oneweb-9035_0 | estrack-kiruna GS | t0 + 14587.0s | 4h 3m 17s from start | 2 |
Charts
charts/network_tx.png
gnuplot/delivery.png
Files
- Kubernetes resources — manifests to reproduce this run (hardwaredefinitions, layout, experimentdefinition, experiment)
- metrics.json — KPIs as JSON
- raw-parquet.tar — raw metrics & events as typed, zstd-compressed Parquet (one file per series; read with pandas/polars/DuckDB)
