YASS results
/ uc2 / uc2-edfs-pdefault-n21-rf3
uc2-edfs-pdefault-n21-rf3
edfs
Success
Parameters
| parameter | value | unit | description |
|---|---|---|---|
| engine | edfs | — | Storage/transport engine under test (edfs or tus) |
| priority | default | — | File priority class (low/default/high; EDFS PAR) |
| sat_count | 21 | sats | Number of satellites in the constellation |
| RF | 3 | copies | EDFS replication factor (n/a for TUS) |
KPIs
| KPI | value | unit | description |
|---|---|---|---|
| state | Success | — | Terminal experiment state (Success/TimedOut/Failure) |
| exec_date | 2026-06-08 23:51 UTC | UTC | Wall-clock date/time the experiment was launched (CR creationTimestamp) |
| duration | 13m 51s | — | Experiment duration on the simulation clock (simulationStartTime → experimentTime) |
| sim_start | 2026-05-16 23:59 UTC | UTC | Simulation clock at experiment start (simulationStartTime) |
| sim_end | 2026-05-17 00:12 UTC | UTC | Simulation clock when the experiment finished (experimentTime) |
| produced | 21 | files | Files produced by the producer agent(s) |
| files_to_GS | 20 | count | Distinct produced files that reached at least one ground station |
| delivery_success_rate | 95 | % | Distinct files reaching ≥1 GS as a percentage of files produced (UC2/UC5 primary KPI) |
| all_delivered | no | — | Whether every produced file reached a ground station |
| first_GS_delivery_s | 24 | s | Time from sim start until the first produced file reached any ground station |
| last_GS_delivery_s | 833 | s | Time from sim start until the last produced file reached a ground station (all-delivered time) |
| GS_reached | 7 | count | Ground stations that received the file (from received_total — independent of the delivery-time metric) |
| distinct_receivers | 28 | count | Distinct nodes that received a file (GS + relays) |
| TX_MiB | 13414 | MiB | Total network bytes transmitted, all nodes |
| peak_cpu_m | 690 | millicores | Peak CPU across all containers |
| peak_mem_MiB | 249 | MiB | Peak memory across all containers |
| notes | 1 of 21 file(s) undelivered | — | Data-quality flags for this run (missing metrics, undelivered files) |
Charts (interactive)
Node colours are consistent across every chart and the graph: ■ ground station · ■ relay satellite · ■ producer.
Per-target delivery time
Seconds from file creation until each target node held the complete file. Bars coloured by node kind; the delivery KPI is the earliest ground-station bar.
Network TX over time (MiB)
Cumulative TX summed across all nodes, vs seconds from experiment start.
CPU and memory over time
Aggregate CPU (millicores, left axis) and memory (MiB, right axis) across all containers, vs seconds from experiment start.
Network TX by node (top 20)
Total bytes transmitted per node over the run, coloured by node kind.
Peak CPU per node (top 20)
Peak CPU (millicores) reached by each fsNode during the run, coloured by node kind.
Peak memory per node (top 20)
Peak memory (MiB) reached by each fsNode during the run, coloured by node kind.
File propagation graph
■ ground station · ● relay satellite · ● producer (same colours as the charts). Spread tree: one edge
from → to per node = where it first acquired the file by the selected time. Grouped per file; 0-byte control messages omitted; times bucketed to ~2 s for cross-node clock skew. Timeline spans the whole experiment (0 = simulation start). Delivery completeness is the File deliveries table below. File transfer graph (rate)
Same nodes; edge
from → to = bytes transferred within the trailing window ending at the selected time (instantaneous flow). Edge colour = bandwidth (bits/s, blue = low → red = high); label shows the rate. Play to watch where traffic moves moment-to-moment. Timeline is the simulation clock (0 = simulation start), shared with the charts above.File deliveries
| file | received by | delivery (s from creation) | time from start | #fsNodes with file |
|---|---|---|---|---|
| oneweb-0006_0 | oneweb-0006 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0006_0 | oneweb-0007 | t0 + 24.3s | 36s from start | 2 |
| oneweb-0006_0 | estrack-malargue GS | t0 + 205.3s | 3m 37s from start | 3 |
| oneweb-0006_0 | estrack-santa-maria GS | t0 + 205.3s | 3m 37s from start | 4 |
| oneweb-0006_0 | estrack-kourou GS | t0 + 205.4s | 3m 37s from start | 5 |
| oneweb-0006_0 | estrack-cebreros GS | t0 + 205.4s | 3m 37s from start | 6 |
| oneweb-0006_0 | estrack-new-norcia GS | t0 + 205.5s | 3m 37s from start | 7 |
| oneweb-0006_0 | estrack-redu GS | t0 + 205.6s | 3m 37s from start | 8 |
| oneweb-0006_0 | estrack-kiruna GS | t0 + 205.6s | 3m 37s from start | 9 |
| oneweb-0006_0 | oneweb-0025 | t0 + 210.8s | 3m 43s from start | 10 |
| oneweb-0006_0 | oneweb-0024 | t0 + 212.1s | 3m 44s from start | 11 |
| oneweb-0006_0 | oneweb-0026 | t0 + 212.6s | 3m 44s from start | 12 |
| oneweb-0006_0 | oneweb-0038 | t0 + 212.8s | 3m 45s from start | 13 |
| oneweb-0006_0 | oneweb-0027 | t0 + 220.3s | 3m 52s from start | 14 |
| oneweb-0006_0 | oneweb-0012 | t0 + 221.4s | 3m 53s from start | 15 |
| oneweb-0007_0 | oneweb-0007 producer | t0 | 14s from start ← t0 | 1 |
| oneweb-0007_0 | oneweb-0006 | t0 + 35.3s | 49s from start | 2 |
| oneweb-0007_0 | oneweb-0038 | t0 + 128.7s | 2m 23s from start | 3 |
| oneweb-0007_0 | oneweb-0024 | t0 + 134.3s | 2m 28s from start | 4 |
| oneweb-0007_0 | oneweb-0008 | t0 + 141.0s | 2m 35s from start | 5 |
| oneweb-0007_0 | oneweb-0025 | t0 + 146.0s | 2m 40s from start | 6 |
| oneweb-0007_0 | oneweb-0020 | t0 + 168.0s | 3m 2s from start | 7 |
| oneweb-0007_0 | oneweb-0026 | t0 + 222.6s | 3m 56s from start | 8 |
| oneweb-0007_0 | estrack-kiruna GS | t0 + 815.5s | 13m 49s from start | 9 |
| oneweb-0007_0 | estrack-malargue GS | t0 + 816.3s | 13m 50s from start | 10 |
| oneweb-0007_0 | estrack-santa-maria GS | t0 + 817.1s | 13m 51s from start | 11 |
| oneweb-0007_0 | estrack-new-norcia GS | t0 + 818.9s | 13m 53s from start | 12 |
| oneweb-0007_0 | estrack-redu GS | t0 + 827.9s | 14m 1s from start | 13 |
| oneweb-0007_0 | estrack-cebreros GS | t0 + 855.0s | 14m 28s from start | 14 |
| oneweb-0008_0 | oneweb-0008 producer | t0 | 14s from start ← t0 | 1 |
| oneweb-0008_0 | oneweb-0024 | t0 + 34.8s | 49s from start | 2 |
| oneweb-0008_0 | oneweb-0025 | t0 + 41.7s | 55s from start | 3 |
| oneweb-0008_0 | oneweb-0020 | t0 + 42.4s | 56s from start | 4 |
| oneweb-0008_0 | oneweb-0038 | t0 + 44.9s | 59s from start | 5 |
| oneweb-0008_0 | oneweb-0037 | t0 + 45.0s | 59s from start | 6 |
| oneweb-0008_0 | oneweb-0029 | t0 + 58.8s | 1m 13s from start | 7 |
| oneweb-0008_0 | oneweb-0007 | t0 + 112.2s | 2m 6s from start | 8 |
| oneweb-0008_0 | oneweb-0031 | t0 + 269.5s | 4m 42s from start | 9 |
| oneweb-0008_0 | estrack-kiruna GS | t0 + 773.3s | 13m 7s from start | 10 |
| oneweb-0008_0 | estrack-malargue GS | t0 + 773.4s | 13m 7s from start | 11 |
| oneweb-0008_0 | estrack-kourou GS | t0 + 773.7s | 13m 7s from start | 12 |
| oneweb-0008_0 | estrack-new-norcia GS | t0 + 774.3s | 13m 8s from start | 13 |
| oneweb-0008_0 | estrack-redu GS | t0 + 842.8s | 14m 16s from start | 14 |
| oneweb-0008_0 | estrack-santa-maria GS | t0 + 847.4s | 14m 21s from start | 15 |
| oneweb-0008_0 | estrack-cebreros GS | t0 + 858.2s | 14m 31s from start | 16 |
| oneweb-0010_0 | oneweb-0010 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0010_0 | oneweb-0023 | t0 + 22.8s | 35s from start | 2 |
| oneweb-0010_0 | oneweb-0013 | t0 + 52.7s | 1m 5s from start | 3 |
| oneweb-0010_0 | oneweb-0028 | t0 + 105.7s | 1m 58s from start | 4 |
| oneweb-0010_0 | oneweb-0031 | t0 + 111.1s | 2m 3s from start | 5 |
| oneweb-0010_0 | oneweb-0021 | t0 + 112.4s | 2m 5s from start | 6 |
| oneweb-0010_0 | oneweb-0011 | t0 + 114.9s | 2m 7s from start | 7 |
| oneweb-0010_0 | estrack-redu GS | t0 + 799.2s | 13m 32s from start | 8 |
| oneweb-0010_0 | estrack-kourou GS | t0 + 799.3s | 13m 32s from start | 9 |
| oneweb-0010_0 | estrack-new-norcia GS | t0 + 800.0s | 13m 32s from start | 10 |
| oneweb-0010_0 | estrack-santa-maria GS | t0 + 800.1s | 13m 32s from start | 11 |
| oneweb-0010_0 | estrack-cebreros GS | t0 + 800.9s | 13m 33s from start | 12 |
| oneweb-0010_0 | estrack-kiruna GS | t0 + 802.5s | 13m 35s from start | 13 |
| oneweb-0011_0 | oneweb-0011 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0011_0 | oneweb-0013 | t0 + 177.9s | 3m 10s from start | 2 |
| oneweb-0011_0 | oneweb-0028 | t0 + 178.1s | 3m 10s from start | 3 |
| oneweb-0011_0 | oneweb-0010 | t0 + 178.1s | 3m 11s from start | 4 |
| oneweb-0011_0 | oneweb-0017 | t0 + 178.1s | 3m 11s from start | 5 |
| oneweb-0011_0 | oneweb-0023 | t0 + 181.0s | 3m 13s from start | 6 |
| oneweb-0011_0 | oneweb-0021 | t0 + 182.3s | 3m 15s from start | 7 |
| oneweb-0011_0 | oneweb-0031 | t0 + 203.1s | 3m 36s from start | 8 |
| oneweb-0011_0 | oneweb-0029 | t0 + 218.4s | 3m 51s from start | 9 |
| oneweb-0011_0 | oneweb-0037 | t0 + 218.9s | 3m 51s from start | 10 |
| oneweb-0011_0 | estrack-cebreros GS | t0 + 785.2s | 13m 18s from start | 11 |
| oneweb-0011_0 | estrack-kiruna GS | t0 + 785.2s | 13m 18s from start | 12 |
| oneweb-0011_0 | estrack-new-norcia GS | t0 + 785.9s | 13m 18s from start | 13 |
| oneweb-0011_0 | estrack-santa-maria GS | t0 + 786.8s | 13m 19s from start | 14 |
| oneweb-0011_0 | estrack-kourou GS | t0 + 791.1s | 13m 24s from start | 15 |
| oneweb-0011_0 | estrack-redu GS | t0 + 795.1s | 13m 28s from start | 16 |
| oneweb-0012_0 | oneweb-0012 producer | t0 | 13s from start ← t0 | 1 |
| oneweb-0012_0 | oneweb-0027 | t0 + 148.9s | 2m 42s from start | 2 |
| oneweb-0012_0 | oneweb-0018 | t0 + 179.9s | 3m 13s from start | 3 |
| oneweb-0012_0 | oneweb-0026 | t0 + 183.9s | 3m 17s from start | 4 |
| oneweb-0012_0 | oneweb-0006 | t0 + 221.9s | 3m 55s from start | 5 |
| oneweb-0012_0 | estrack-santa-maria GS | t0 + 820.3s | 13m 53s from start | 6 |
| oneweb-0012_0 | estrack-malargue GS | t0 + 820.5s | 13m 53s from start | 7 |
| oneweb-0012_0 | estrack-cebreros GS | t0 + 820.6s | 13m 53s from start | 8 |
| oneweb-0012_0 | estrack-redu GS | t0 + 820.9s | 13m 54s from start | 9 |
| oneweb-0012_0 | estrack-kiruna GS | t0 + 821.1s | 13m 54s from start | 10 |
| oneweb-0012_0 | estrack-new-norcia GS | t0 + 821.4s | 13m 54s from start | 11 |
| oneweb-0013_0 | oneweb-0013 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0013_0 | oneweb-0010 | t0 + 56.9s | 1m 9s from start | 2 |
| oneweb-0013_0 | oneweb-0028 | t0 + 57.9s | 1m 10s from start | 3 |
| oneweb-0013_0 | oneweb-0023 | t0 + 64.5s | 1m 17s from start | 4 |
| oneweb-0013_0 | oneweb-0021 | t0 + 121.3s | 2m 14s from start | 5 |
| oneweb-0013_0 | oneweb-0031 | t0 + 123.5s | 2m 16s from start | 6 |
| oneweb-0013_0 | oneweb-0011 | t0 + 126.2s | 2m 19s from start | 7 |
| oneweb-0013_0 | estrack-kiruna GS | t0 + 289.7s | 5m 2s from start | 8 |
| oneweb-0013_0 | estrack-kourou GS | t0 + 289.9s | 5m 2s from start | 9 |
| oneweb-0013_0 | estrack-malargue GS | t0 + 289.9s | 5m 2s from start | 10 |
| oneweb-0013_0 | estrack-new-norcia GS | t0 + 289.9s | 5m 2s from start | 11 |
| oneweb-0013_0 | estrack-santa-maria GS | t0 + 290.0s | 5m 2s from start | 12 |
| oneweb-0013_0 | estrack-redu GS | t0 + 290.2s | 5m 3s from start | 13 |
| oneweb-0013_0 | estrack-cebreros GS | t0 + 290.2s | 5m 3s from start | 14 |
| oneweb-0017_0 | oneweb-0017 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0017_0 | oneweb-0010 | t0 + 41.0s | 53s from start | 2 |
| oneweb-0017_0 | oneweb-0013 | t0 + 41.6s | 54s from start | 3 |
| oneweb-0017_0 | oneweb-0023 | t0 + 59.3s | 1m 11s from start | 4 |
| oneweb-0017_0 | oneweb-0028 | t0 + 117.0s | 2m 9s from start | 5 |
| oneweb-0017_0 | oneweb-0011 | t0 + 214.3s | 3m 46s from start | 6 |
| oneweb-0018_0 | oneweb-0018 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0018_0 | oneweb-0027 | t0 + 178.4s | 3m 10s from start | 2 |
| oneweb-0018_0 | oneweb-0012 | t0 + 180.1s | 3m 12s from start | 3 |
| oneweb-0018_0 | estrack-new-norcia GS | t0 + 760.2s | 12m 52s from start | 4 |
| oneweb-0018_0 | estrack-malargue GS | t0 + 760.3s | 12m 52s from start | 5 |
| oneweb-0018_0 | estrack-santa-maria GS | t0 + 760.5s | 12m 52s from start | 6 |
| oneweb-0018_0 | estrack-kourou GS | t0 + 760.8s | 12m 53s from start | 7 |
| oneweb-0018_0 | estrack-cebreros GS | t0 + 760.8s | 12m 53s from start | 8 |
| oneweb-0018_0 | estrack-kiruna GS | t0 + 760.8s | 12m 53s from start | 9 |
| oneweb-0020_0 | oneweb-0020 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0020_0 | oneweb-0024 | t0 + 46.0s | 58s from start | 2 |
| oneweb-0020_0 | oneweb-0008 | t0 + 51.3s | 1m 3s from start | 3 |
| oneweb-0020_0 | oneweb-0029 | t0 + 52.0s | 1m 4s from start | 4 |
| oneweb-0020_0 | oneweb-0025 | t0 + 57.4s | 1m 9s from start | 5 |
| oneweb-0020_0 | oneweb-0037 | t0 + 57.7s | 1m 9s from start | 6 |
| oneweb-0020_0 | oneweb-0031 | t0 + 166.7s | 2m 58s from start | 7 |
| oneweb-0020_0 | estrack-kourou GS | t0 + 276.3s | 4m 48s from start | 8 |
| oneweb-0020_0 | estrack-kiruna GS | t0 + 276.3s | 4m 48s from start | 9 |
| oneweb-0020_0 | estrack-malargue GS | t0 + 276.3s | 4m 48s from start | 10 |
| oneweb-0020_0 | estrack-new-norcia GS | t0 + 276.4s | 4m 48s from start | 11 |
| oneweb-0020_0 | oneweb-0007 | t0 + 282.6s | 4m 54s from start | 12 |
| oneweb-0020_0 | estrack-santa-maria GS | t0 + 838.4s | 14m 9s from start | 13 |
| oneweb-0020_0 | estrack-redu GS | t0 + 841.8s | 14m 13s from start | 14 |
| oneweb-0020_0 | estrack-cebreros GS | t0 + 859.1s | 14m 30s from start | 15 |
| oneweb-0021_0 | oneweb-0021 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0021_0 | oneweb-0031 | t0 + 194.2s | 3m 26s from start | 2 |
| oneweb-0021_0 | oneweb-0011 | t0 + 199.6s | 3m 31s from start | 3 |
| oneweb-0021_0 | oneweb-0029 | t0 + 214.2s | 3m 46s from start | 4 |
| oneweb-0021_0 | oneweb-0008 | t0 + 214.4s | 3m 46s from start | 5 |
| oneweb-0021_0 | oneweb-0037 | t0 + 214.4s | 3m 46s from start | 6 |
| oneweb-0021_0 | oneweb-0010 | t0 + 220.3s | 3m 52s from start | 7 |
| oneweb-0021_0 | oneweb-0028 | t0 + 220.9s | 3m 53s from start | 8 |
| oneweb-0021_0 | oneweb-0013 | t0 + 221.7s | 3m 53s from start | 9 |
| oneweb-0021_0 | oneweb-0023 | t0 + 222.2s | 3m 54s from start | 10 |
| oneweb-0021_0 | estrack-kourou GS | t0 + 294.3s | 5m 6s from start | 11 |
| oneweb-0021_0 | estrack-malargue GS | t0 + 294.3s | 5m 6s from start | 12 |
| oneweb-0021_0 | estrack-santa-maria GS | t0 + 294.4s | 5m 6s from start | 13 |
| oneweb-0021_0 | estrack-kiruna GS | t0 + 294.5s | 5m 6s from start | 14 |
| oneweb-0021_0 | estrack-cebreros GS | t0 + 294.7s | 5m 6s from start | 15 |
| oneweb-0021_0 | estrack-redu GS | t0 + 294.7s | 5m 6s from start | 16 |
| oneweb-0021_0 | estrack-new-norcia GS | t0 + 295.3s | 5m 7s from start | 17 |
| oneweb-0023_0 | oneweb-0023 producer | t0 | 14s from start ← t0 | 1 |
| oneweb-0023_0 | oneweb-0017 | t0 + 132.2s | 2m 26s from start | 2 |
| oneweb-0023_0 | oneweb-0013 | t0 + 133.1s | 2m 27s from start | 3 |
| oneweb-0023_0 | oneweb-0010 | t0 + 133.3s | 2m 27s from start | 4 |
| oneweb-0023_0 | oneweb-0028 | t0 + 135.8s | 2m 30s from start | 5 |
| oneweb-0023_0 | oneweb-0011 | t0 + 163.0s | 2m 57s from start | 6 |
| oneweb-0023_0 | oneweb-0021 | t0 + 220.9s | 3m 55s from start | 7 |
| oneweb-0023_0 | oneweb-0031 | t0 + 250.4s | 4m 24s from start | 8 |
| oneweb-0023_0 | estrack-santa-maria GS | t0 + 832.9s | 14m 6s from start | 9 |
| oneweb-0023_0 | estrack-malargue GS | t0 + 833.1s | 14m 7s from start | 10 |
| oneweb-0023_0 | estrack-kiruna GS | t0 + 833.8s | 14m 7s from start | 11 |
| oneweb-0023_0 | estrack-cebreros GS | t0 + 834.0s | 14m 8s from start | 12 |
| oneweb-0023_0 | estrack-new-norcia GS | t0 + 834.0s | 14m 8s from start | 13 |
| oneweb-0023_0 | estrack-redu GS | t0 + 835.0s | 14m 9s from start | 14 |
| oneweb-0024_0 | oneweb-0024 producer | t0 | 10s from start ← t0 | 1 |
| oneweb-0024_0 | oneweb-0020 | t0 + 70.6s | 1m 21s from start | 2 |
| oneweb-0024_0 | oneweb-0029 | t0 + 110.6s | 2m 2s from start | 3 |
| oneweb-0024_0 | oneweb-0037 | t0 + 119.4s | 2m 11s from start | 4 |
| oneweb-0024_0 | oneweb-0025 | t0 + 136.7s | 2m 28s from start | 5 |
| oneweb-0024_0 | oneweb-0038 | t0 + 171.7s | 3m 3s from start | 6 |
| oneweb-0024_0 | oneweb-0007 | t0 + 208.2s | 3m 40s from start | 7 |
| oneweb-0024_0 | estrack-redu GS | t0 + 310.7s | 5m 22s from start | 8 |
| oneweb-0024_0 | estrack-new-norcia GS | t0 + 310.9s | 5m 22s from start | 9 |
| oneweb-0024_0 | estrack-malargue GS | t0 + 310.9s | 5m 22s from start | 10 |
| oneweb-0024_0 | estrack-kiruna GS | t0 + 310.9s | 5m 22s from start | 11 |
| oneweb-0024_0 | estrack-kourou GS | t0 + 310.9s | 5m 22s from start | 12 |
| oneweb-0024_0 | estrack-santa-maria GS | t0 + 840.3s | 14m 11s from start | 13 |
| oneweb-0024_0 | estrack-cebreros GS | t0 + 865.4s | 14m 36s from start | 14 |
| oneweb-0025_0 | oneweb-0025 producer | t0 | 13s from start ← t0 | 1 |
| oneweb-0025_0 | oneweb-0020 | t0 + 145.9s | 2m 39s from start | 2 |
| oneweb-0025_0 | oneweb-0037 | t0 + 149.3s | 2m 43s from start | 3 |
| oneweb-0025_0 | oneweb-0038 | t0 + 149.4s | 2m 43s from start | 4 |
| oneweb-0025_0 | oneweb-0029 | t0 + 149.7s | 2m 43s from start | 5 |
| oneweb-0025_0 | oneweb-0008 | t0 + 150.8s | 2m 44s from start | 6 |
| oneweb-0025_0 | oneweb-0024 | t0 + 157.4s | 2m 51s from start | 7 |
| oneweb-0025_0 | oneweb-0007 | t0 + 285.6s | 4m 59s from start | 8 |
| oneweb-0025_0 | oneweb-0006 | t0 + 293.0s | 5m 6s from start | 9 |
| oneweb-0025_0 | estrack-kiruna GS | t0 + 797.7s | 13m 31s from start | 10 |
| oneweb-0025_0 | estrack-malargue GS | t0 + 799.9s | 13m 33s from start | 11 |
| oneweb-0025_0 | estrack-new-norcia GS | t0 + 800.8s | 13m 34s from start | 12 |
| oneweb-0025_0 | estrack-kourou GS | t0 + 804.2s | 13m 37s from start | 13 |
| oneweb-0025_0 | estrack-redu GS | t0 + 808.3s | 13m 42s from start | 14 |
| oneweb-0025_0 | estrack-santa-maria GS | t0 + 840.4s | 14m 13s from start | 15 |
| oneweb-0025_0 | estrack-cebreros GS | t0 + 862.0s | 14m 35s from start | 16 |
| oneweb-0026_0 | oneweb-0026 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0026_0 | oneweb-0012 | t0 + 158.9s | 2m 51s from start | 2 |
| oneweb-0026_0 | oneweb-0027 | t0 + 158.9s | 2m 51s from start | 3 |
| oneweb-0026_0 | oneweb-0038 | t0 + 247.6s | 4m 20s from start | 4 |
| oneweb-0026_0 | oneweb-0006 | t0 + 261.5s | 4m 33s from start | 5 |
| oneweb-0026_0 | oneweb-0007 | t0 + 262.7s | 4m 34s from start | 6 |
| oneweb-0026_0 | estrack-redu GS | t0 + 792.0s | 13m 24s from start | 7 |
| oneweb-0026_0 | estrack-cebreros GS | t0 + 792.1s | 13m 24s from start | 8 |
| oneweb-0026_0 | estrack-new-norcia GS | t0 + 792.1s | 13m 24s from start | 9 |
| oneweb-0026_0 | estrack-santa-maria GS | t0 + 792.1s | 13m 24s from start | 10 |
| oneweb-0026_0 | estrack-kiruna GS | t0 + 792.4s | 13m 25s from start | 11 |
| oneweb-0026_0 | estrack-kourou GS | t0 + 792.5s | 13m 25s from start | 12 |
| oneweb-0027_0 | oneweb-0027 producer | t0 | 11s from start ← t0 | 1 |
| oneweb-0027_0 | oneweb-0012 | t0 + 98.4s | 1m 50s from start | 2 |
| oneweb-0027_0 | oneweb-0018 | t0 + 127.4s | 2m 19s from start | 3 |
| oneweb-0027_0 | oneweb-0026 | t0 + 231.4s | 4m 3s from start | 4 |
| oneweb-0027_0 | oneweb-0006 | t0 + 288.1s | 4m 59s from start | 5 |
| oneweb-0027_0 | estrack-malargue GS | t0 + 767.0s | 12m 58s from start | 6 |
| oneweb-0027_0 | estrack-new-norcia GS | t0 + 767.0s | 12m 58s from start | 7 |
| oneweb-0027_0 | estrack-santa-maria GS | t0 + 767.2s | 12m 58s from start | 8 |
| oneweb-0027_0 | estrack-kiruna GS | t0 + 767.3s | 12m 59s from start | 9 |
| oneweb-0027_0 | estrack-kourou GS | t0 + 767.4s | 12m 59s from start | 10 |
| oneweb-0027_0 | estrack-cebreros GS | t0 + 768.0s | 12m 59s from start | 11 |
| oneweb-0028_0 | oneweb-0028 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0028_0 | oneweb-0013 | t0 + 117.5s | 2m 9s from start | 2 |
| oneweb-0028_0 | oneweb-0017 | t0 + 119.0s | 2m 11s from start | 3 |
| oneweb-0028_0 | oneweb-0023 | t0 + 120.6s | 2m 12s from start | 4 |
| oneweb-0028_0 | oneweb-0010 | t0 + 120.8s | 2m 13s from start | 5 |
| oneweb-0028_0 | oneweb-0021 | t0 + 139.5s | 2m 31s from start | 6 |
| oneweb-0028_0 | oneweb-0011 | t0 + 141.4s | 2m 33s from start | 7 |
| oneweb-0028_0 | oneweb-0031 | t0 + 141.9s | 2m 34s from start | 8 |
| oneweb-0028_0 | estrack-kiruna GS | t0 + 304.5s | 5m 16s from start | 9 |
| oneweb-0028_0 | estrack-santa-maria GS | t0 + 304.7s | 5m 16s from start | 10 |
| oneweb-0028_0 | estrack-new-norcia GS | t0 + 304.9s | 5m 17s from start | 11 |
| oneweb-0028_0 | estrack-kourou GS | t0 + 305.0s | 5m 17s from start | 12 |
| oneweb-0028_0 | estrack-redu GS | t0 + 305.0s | 5m 17s from start | 13 |
| oneweb-0028_0 | estrack-malargue GS | t0 + 305.0s | 5m 17s from start | 14 |
| oneweb-0028_0 | estrack-cebreros GS | t0 + 305.0s | 5m 17s from start | 15 |
| oneweb-0029_0 | oneweb-0029 producer | t0 | 15s from start ← t0 | 1 |
| oneweb-0029_0 | oneweb-0037 | t0 + 33.4s | 48s from start | 2 |
| oneweb-0029_0 | oneweb-0020 | t0 + 55.3s | 1m 10s from start | 3 |
| oneweb-0029_0 | oneweb-0008 | t0 + 57.3s | 1m 12s from start | 4 |
| oneweb-0029_0 | oneweb-0025 | t0 + 93.1s | 1m 48s from start | 5 |
| oneweb-0029_0 | oneweb-0024 | t0 + 96.1s | 1m 51s from start | 6 |
| oneweb-0029_0 | oneweb-0038 | t0 + 182.0s | 3m 17s from start | 7 |
| oneweb-0029_0 | oneweb-0021 | t0 + 187.1s | 3m 22s from start | 8 |
| oneweb-0029_0 | oneweb-0031 | t0 + 239.2s | 4m 14s from start | 9 |
| oneweb-0029_0 | oneweb-0011 | t0 + 262.4s | 4m 36s from start | 10 |
| oneweb-0029_0 | estrack-kiruna GS | t0 + 821.6s | 13m 57s from start | 11 |
| oneweb-0029_0 | estrack-malargue GS | t0 + 827.4s | 14m 2s from start | 12 |
| oneweb-0029_0 | estrack-santa-maria GS | t0 + 827.7s | 14m 2s from start | 13 |
| oneweb-0029_0 | estrack-new-norcia GS | t0 + 828.8s | 14m 3s from start | 14 |
| oneweb-0029_0 | estrack-redu GS | t0 + 844.4s | 14m 19s from start | 15 |
| oneweb-0029_0 | estrack-cebreros GS | t0 + 863.0s | 14m 37s from start | 16 |
| oneweb-0031_0 | oneweb-0031 producer | t0 | 13s from start ← t0 | 1 |
| oneweb-0031_0 | oneweb-0021 | t0 + 163.9s | 2m 57s from start | 2 |
| oneweb-0031_0 | oneweb-0020 | t0 + 196.4s | 3m 29s from start | 3 |
| oneweb-0031_0 | oneweb-0008 | t0 + 198.3s | 3m 31s from start | 4 |
| oneweb-0031_0 | oneweb-0029 | t0 + 200.2s | 3m 33s from start | 5 |
| oneweb-0031_0 | oneweb-0037 | t0 + 200.5s | 3m 33s from start | 6 |
| oneweb-0031_0 | oneweb-0011 | t0 + 207.1s | 3m 40s from start | 7 |
| oneweb-0031_0 | oneweb-0013 | t0 + 229.1s | 4m 2s from start | 8 |
| oneweb-0031_0 | oneweb-0010 | t0 + 230.5s | 4m 3s from start | 9 |
| oneweb-0031_0 | oneweb-0023 | t0 + 230.8s | 4m 4s from start | 10 |
| oneweb-0031_0 | oneweb-0028 | t0 + 232.4s | 4m 5s from start | 11 |
| oneweb-0031_0 | estrack-kiruna GS | t0 + 808.8s | 13m 42s from start | 12 |
| oneweb-0031_0 | estrack-kourou GS | t0 + 809.8s | 13m 43s from start | 13 |
| oneweb-0031_0 | estrack-malargue GS | t0 + 811.3s | 13m 44s from start | 14 |
| oneweb-0031_0 | estrack-new-norcia GS | t0 + 811.8s | 13m 45s from start | 15 |
| oneweb-0031_0 | estrack-cebreros GS | t0 + 813.5s | 13m 46s from start | 16 |
| oneweb-0031_0 | estrack-santa-maria GS | t0 + 813.8s | 13m 47s from start | 17 |
| oneweb-0031_0 | estrack-redu GS | t0 + 824.7s | 13m 57s from start | 18 |
| oneweb-0037_0 | oneweb-0037 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0037_0 | estrack-santa-maria GS | t0 + 23.6s | 36s from start | 2 |
| oneweb-0037_0 | estrack-kiruna GS | t0 + 23.6s | 36s from start | 3 |
| oneweb-0037_0 | estrack-malargue GS | t0 + 23.7s | 36s from start | 4 |
| oneweb-0037_0 | estrack-kourou GS | t0 + 23.7s | 36s from start | 5 |
| oneweb-0037_0 | estrack-new-norcia GS | t0 + 23.9s | 36s from start | 6 |
| oneweb-0037_0 | estrack-redu GS | t0 + 24.0s | 36s from start | 7 |
| oneweb-0037_0 | estrack-cebreros GS | t0 + 24.3s | 36s from start | 8 |
| oneweb-0037_0 | oneweb-0029 | t0 + 65.2s | 1m 17s from start | 9 |
| oneweb-0037_0 | oneweb-0020 | t0 + 98.0s | 1m 50s from start | 10 |
| oneweb-0037_0 | oneweb-0024 | t0 + 150.1s | 2m 42s from start | 11 |
| oneweb-0037_0 | oneweb-0025 | t0 + 157.6s | 2m 50s from start | 12 |
| oneweb-0037_0 | oneweb-0038 | t0 + 192.7s | 3m 25s from start | 13 |
| oneweb-0037_0 | oneweb-0021 | t0 + 217.2s | 3m 49s from start | 14 |
| oneweb-0037_0 | oneweb-0031 | t0 + 230.6s | 4m 3s from start | 15 |
| oneweb-0037_0 | oneweb-0011 | t0 + 260.2s | 4m 31s from start | 16 |
| oneweb-0038_0 | oneweb-0038 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0038_0 | oneweb-0008 | t0 + 130.2s | 2m 22s from start | 2 |
| oneweb-0038_0 | oneweb-0020 | t0 + 135.5s | 2m 27s from start | 3 |
| oneweb-0038_0 | oneweb-0024 | t0 + 144.6s | 2m 36s from start | 4 |
| oneweb-0038_0 | oneweb-0025 | t0 + 166.8s | 2m 59s from start | 5 |
| oneweb-0038_0 | oneweb-0037 | t0 + 174.2s | 3m 6s from start | 6 |
| oneweb-0038_0 | oneweb-0029 | t0 + 175.0s | 3m 7s from start | 7 |
| oneweb-0038_0 | oneweb-0007 | t0 + 183.3s | 3m 15s from start | 8 |
| oneweb-0038_0 | oneweb-0006 | t0 + 269.5s | 4m 40s from start | 9 |
| oneweb-0038_0 | oneweb-0026 | t0 + 310.0s | 5m 22s from start | 10 |
| oneweb-0038_0 | estrack-kiruna GS | t0 + 767.6s | 12m 59s from start | 11 |
| oneweb-0038_0 | estrack-santa-maria GS | t0 + 768.6s | 13m 0s from start | 12 |
| oneweb-0038_0 | estrack-cebreros GS | t0 + 769.1s | 13m 1s from start | 13 |
| oneweb-0038_0 | estrack-malargue GS | t0 + 769.1s | 13m 1s from start | 14 |
| oneweb-0038_0 | estrack-new-norcia GS | t0 + 770.0s | 13m 2s from start | 15 |
| oneweb-0038_0 | estrack-kourou GS | t0 + 771.5s | 13m 3s from start | 16 |
Charts
charts/network_tx.png
gnuplot/delivery.png
Files
- Kubernetes resources — manifests to reproduce this run (hardwaredefinitions, layout, experimentdefinition, experiment)
- metrics.json — KPIs as JSON
- raw-parquet.tar — raw metrics & events as typed, zstd-compressed Parquet (one file per series; read with pandas/polars/DuckDB)
