YASS results
/ uc2nr / uc2nr-edfs-pdefault-n21-rf3
uc2nr-edfs-pdefault-n21-rf3
edfs
Success
Parameters
| parameter | value | unit | description |
|---|---|---|---|
| engine | edfs | — | Storage/transport engine under test (edfs or tus) |
| priority | default | — | File priority class (low/default/high; EDFS PAR) |
| sat_count | 21 | sats | Number of satellites in the constellation |
| RF | 3 | copies | EDFS replication factor (n/a for TUS) |
KPIs
| KPI | value | unit | description |
|---|---|---|---|
| state | Success | — | Terminal experiment state (Success/TimedOut/Failure) |
| exec_date | 2026-06-10 19:46 UTC | UTC | Wall-clock date/time the experiment was launched (CR creationTimestamp) |
| duration | 53m 36s | — | Experiment duration on the simulation clock (simulationStartTime → experimentTime) |
| sim_start | 2026-05-16 23:59 UTC | UTC | Simulation clock at experiment start (simulationStartTime) |
| sim_end | 2026-05-17 00:52 UTC | UTC | Simulation clock when the experiment finished (experimentTime) |
| produced | 21 | files | Files produced by the producer agent(s) |
| files_to_GS | 19 | count | Distinct produced files that reached at least one ground station |
| delivery_success_rate | 90 | % | Distinct files reaching ≥1 GS as a percentage of files produced (UC2/UC5 primary KPI) |
| all_delivered | no | — | Whether every produced file reached a ground station |
| first_GS_delivery_s | 242 | s | Time from sim start until the first produced file reached any ground station |
| last_GS_delivery_s | 3207 | s | Time from sim start until the last produced file reached a ground station (all-delivered time) |
| GS_reached | 7 | count | Ground stations that received the file (from received_total — independent of the delivery-time metric) |
| distinct_receivers | 28 | count | Distinct nodes that received a file (GS + relays) |
| TX_MiB | 8407 | MiB | Total network bytes transmitted, all nodes |
| peak_cpu_m | 540 | millicores | Peak CPU across all containers |
| peak_mem_MiB | 224 | MiB | Peak memory across all containers |
| notes | 2 of 21 file(s) undelivered | — | Data-quality flags for this run (missing metrics, undelivered files) |
Charts (interactive)
Node colours are consistent across every chart and the graph: ■ ground station · ■ relay satellite · ■ producer.
Per-target delivery time
Seconds from file creation until each target node held the complete file. Bars coloured by node kind; the delivery KPI is the earliest ground-station bar.
Network TX over time (MiB)
Cumulative TX summed across all nodes, vs seconds from experiment start.
CPU and memory over time
Aggregate CPU (millicores, left axis) and memory (MiB, right axis) across all containers, vs seconds from experiment start.
Network TX by node (top 20)
Total bytes transmitted per node over the run, coloured by node kind.
Peak CPU per node (top 20)
Peak CPU (millicores) reached by each fsNode during the run, coloured by node kind.
Peak memory per node (top 20)
Peak memory (MiB) reached by each fsNode during the run, coloured by node kind.
File propagation graph
■ ground station · ● relay satellite · ● producer (same colours as the charts). Spread tree: one edge
from → to per node = where it first acquired the file by the selected time. Grouped per file; 0-byte control messages omitted; times bucketed to ~2 s for cross-node clock skew. Timeline spans the whole experiment (0 = simulation start). Delivery completeness is the File deliveries table below. File transfer graph (rate)
Same nodes; edge
from → to = bytes transferred within the trailing window ending at the selected time (instantaneous flow). Edge colour = bandwidth (bits/s, blue = low → red = high); label shows the rate. Play to watch where traffic moves moment-to-moment. Timeline is the simulation clock (0 = simulation start), shared with the charts above.File deliveries
| file | received by | delivery (s from creation) | time from start | #fsNodes with file |
|---|---|---|---|---|
| flock-4be-23_0 | flock-4be-23 producer | t0 | 14s from start ← t0 | 1 |
| flock-4be-23_0 | lemur-2-marache-fran | t0 + 107.4s | 2m 2s from start | 2 |
| flock-4be-23_0 | iridium-106 | t0 + 109.2s | 2m 3s from start | 3 |
| flock-4be-23_0 | globalstar-m082 | t0 + 142.9s | 2m 37s from start | 4 |
| flock-4be-23_0 | orbcomm-fm112 | t0 + 180.9s | 3m 15s from start | 5 |
| flock-4be-23_0 | estrack-redu GS | t0 + 2117.2s | 35m 31s from start | 6 |
| flock-4be-23_0 | estrack-new-norcia GS | t0 + 2117.4s | 35m 32s from start | 7 |
| flock-4be-23_0 | estrack-kourou GS | t0 + 2117.5s | 35m 32s from start | 8 |
| flock-4be-23_0 | estrack-kiruna GS | t0 + 2117.8s | 35m 32s from start | 9 |
| flock-4be-23_0 | estrack-malargue GS | t0 + 2118.0s | 35m 32s from start | 10 |
| flock-4be-23_0 | estrack-santa-maria GS | t0 + 3251.1s | 54m 24s from start | 11 |
| flock-4g-36_0 | flock-4g-36 producer | t0 | 13s from start ← t0 | 1 |
| flock-4g-36_0 | skysat-c12 | t0 + 125.1s | 2m 18s from start | 2 |
| flock-4g-36_0 | flock-4h-14 | t0 + 127.1s | 2m 20s from start | 3 |
| flock-4g-36_0 | oneweb-0012 | t0 + 130.1s | 2m 23s from start | 4 |
| flock-4g-36_0 | oneweb-0334 | t0 + 181.5s | 3m 14s from start | 5 |
| flock-4g-36_0 | oneweb-0519 | t0 + 184.6s | 3m 18s from start | 6 |
| flock-4g-36_0 | orbcomm-fm06 | t0 + 233.0s | 4m 6s from start | 7 |
| flock-4g-36_0 | estrack-santa-maria GS | t0 + 1628.1s | 27m 21s from start | 8 |
| flock-4g-36_0 | estrack-new-norcia GS | t0 + 2122.5s | 35m 35s from start | 9 |
| flock-4g-36_0 | estrack-malargue GS | t0 + 2124.3s | 35m 37s from start | 10 |
| flock-4g-36_0 | estrack-kiruna GS | t0 + 2125.4s | 35m 38s from start | 11 |
| flock-4g-36_0 | estrack-redu GS | t0 + 3210.9s | 53m 43s from start | 12 |
| flock-4g-36_0 | estrack-kourou GS | t0 + 3211.3s | 53m 43s from start | 13 |
| flock-4g-36_0 | estrack-cebreros GS | t0 + 3215.1s | 53m 47s from start | 14 |
| flock-4g-7_0 | flock-4g-7 producer | t0 | 15s from start ← t0 | 1 |
| flock-4g-7_0 | iridium-136 | t0 + 61.1s | 1m 16s from start | 2 |
| flock-4g-7_0 | lemur-2-deanandmaeve | t0 + 99.5s | 1m 55s from start | 3 |
| flock-4g-7_0 | iridium-147 | t0 + 168.9s | 3m 4s from start | 4 |
| flock-4g-7_0 | estrack-cebreros GS | t0 + 1610.2s | 27m 6s from start | 5 |
| flock-4g-7_0 | estrack-santa-maria GS | t0 + 1610.4s | 27m 6s from start | 6 |
| flock-4g-7_0 | estrack-kiruna GS | t0 + 1610.5s | 27m 6s from start | 7 |
| flock-4g-7_0 | estrack-malargue GS | t0 + 1611.2s | 27m 7s from start | 8 |
| flock-4g-7_0 | estrack-new-norcia GS | t0 + 1626.2s | 27m 22s from start | 9 |
| flock-4g-7_0 | estrack-redu GS | t0 + 2120.3s | 35m 36s from start | 10 |
| flock-4g-7_0 | estrack-kourou GS | t0 + 2121.3s | 35m 37s from start | 11 |
| flock-4h-14_0 | flock-4h-14 producer | t0 | 16s from start ← t0 | 1 |
| flock-4h-14_0 | skysat-c12 | t0 + 83.2s | 1m 40s from start | 2 |
| flock-4h-14_0 | oneweb-0519 | t0 + 88.2s | 1m 45s from start | 3 |
| flock-4h-14_0 | oneweb-0012 | t0 + 92.2s | 1m 49s from start | 4 |
| flock-4h-14_0 | oneweb-0334 | t0 + 92.8s | 1m 49s from start | 5 |
| flock-4h-14_0 | flock-4g-36 | t0 + 98.1s | 1m 55s from start | 6 |
| flock-4h-14_0 | estrack-santa-maria GS | t0 + 1632.2s | 27m 29s from start | 7 |
| flock-4h-14_0 | estrack-new-norcia GS | t0 + 2142.8s | 35m 59s from start | 8 |
| flock-4h-14_0 | estrack-malargue GS | t0 + 2143.7s | 36m 0s from start | 9 |
| flock-4h-14_0 | estrack-kiruna GS | t0 + 2164.0s | 36m 20s from start | 10 |
| flock-4h-14_0 | estrack-redu GS | t0 + 3211.7s | 53m 47s from start | 11 |
| flock-4h-14_0 | estrack-kourou GS | t0 + 3212.6s | 53m 48s from start | 12 |
| flock-4h-14_0 | estrack-cebreros GS | t0 + 3215.6s | 53m 51s from start | 13 |
| globalstar-m077_0 | globalstar-m077 producer | t0 | 12s from start ← t0 | 1 |
| globalstar-m077_0 | skysat-c12 | t0 + 43.7s | 56s from start | 2 |
| globalstar-m077_0 | oneweb-0209 | t0 + 69.2s | 1m 21s from start | 3 |
| globalstar-m077_0 | lemur-1 | t0 + 86.4s | 1m 38s from start | 4 |
| globalstar-m077_0 | oneweb-0012 | t0 + 159.2s | 2m 51s from start | 5 |
| globalstar-m077_0 | orbcomm-fm06 | t0 + 191.6s | 3m 23s from start | 6 |
| globalstar-m077_0 | estrack-kourou GS | t0 + 1405.1s | 23m 37s from start | 7 |
| globalstar-m077_0 | estrack-redu GS | t0 + 1405.2s | 23m 37s from start | 8 |
| globalstar-m077_0 | estrack-new-norcia GS | t0 + 1405.3s | 23m 37s from start | 9 |
| globalstar-m077_0 | estrack-kiruna GS | t0 + 1405.5s | 23m 37s from start | 10 |
| globalstar-m077_0 | estrack-santa-maria GS | t0 + 1405.5s | 23m 37s from start | 11 |
| globalstar-m077_0 | estrack-cebreros GS | t0 + 1410.2s | 23m 42s from start | 12 |
| globalstar-m077_0 | estrack-malargue GS | t0 + 1412.5s | 23m 44s from start | 13 |
| globalstar-m082_0 | globalstar-m082 producer | t0 | 15s from start ← t0 | 1 |
| globalstar-m082_0 | flock-4be-23 | t0 + 74.2s | 1m 29s from start | 2 |
| globalstar-m082_0 | iridium-106 | t0 + 125.7s | 2m 21s from start | 3 |
| globalstar-m082_0 | oneweb-0334 | t0 + 302.0s | 5m 17s from start | 4 |
| globalstar-m082_0 | orbcomm-fm06 | t0 + 336.4s | 5m 51s from start | 5 |
| globalstar-m082_0 | estrack-kiruna GS | t0 + 2169.9s | 36m 25s from start | 6 |
| globalstar-m082_0 | estrack-new-norcia GS | t0 + 2170.7s | 36m 26s from start | 7 |
| globalstar-m082_0 | estrack-malargue GS | t0 + 2170.9s | 36m 26s from start | 8 |
| globalstar-m082_0 | estrack-santa-maria GS | t0 + 2171.1s | 36m 26s from start | 9 |
| globalstar-m082_0 | estrack-redu GS | t0 + 3215.4s | 53m 49s from start | 10 |
| globalstar-m082_0 | estrack-kourou GS | t0 + 3216.1s | 53m 50s from start | 11 |
| globalstar-m082_0 | estrack-cebreros GS | t0 + 3219.1s | 53m 53s from start | 12 |
| iridium-106_0 | iridium-106 producer | t0 | 17s from start ← t0 | 1 |
| iridium-106_0 | lemur-2-marache-fran | t0 + 46.6s | 1m 4s from start | 2 |
| iridium-106_0 | flock-4be-23 | t0 + 103.5s | 2m 1s from start | 3 |
| iridium-106_0 | globalstar-m082 | t0 + 196.9s | 3m 34s from start | 4 |
| iridium-136_0 | iridium-136 producer | t0 | 11s from start ← t0 | 1 |
| iridium-136_0 | oneweb-0548 | t0 + 23.6s | 35s from start | 2 |
| iridium-136_0 | flock-4g-7 | t0 + 62.8s | 1m 14s from start | 3 |
| iridium-136_0 | lemur-2-deanandmaeve | t0 + 107.2s | 1m 58s from start | 4 |
| iridium-136_0 | estrack-redu GS | t0 + 1586.0s | 26m 37s from start | 5 |
| iridium-136_0 | estrack-cebreros GS | t0 + 1586.2s | 26m 37s from start | 6 |
| iridium-136_0 | estrack-new-norcia GS | t0 + 1586.2s | 26m 38s from start | 7 |
| iridium-136_0 | estrack-kiruna GS | t0 + 1586.5s | 26m 38s from start | 8 |
| iridium-136_0 | estrack-kourou GS | t0 + 1586.6s | 26m 38s from start | 9 |
| iridium-136_0 | estrack-malargue GS | t0 + 1587.7s | 26m 39s from start | 10 |
| iridium-136_0 | estrack-santa-maria GS | t0 + 1588.0s | 26m 39s from start | 11 |
| iridium-147_0 | iridium-147 producer | t0 | 15s from start ← t0 | 1 |
| iridium-147_0 | oneweb-0548 | t0 + 137.4s | 2m 33s from start | 2 |
| iridium-147_0 | flock-4g-7 | t0 + 138.2s | 2m 34s from start | 3 |
| iridium-147_0 | lemur-1 | t0 + 257.3s | 4m 33s from start | 4 |
| iridium-147_0 | oneweb-0209 | t0 + 260.0s | 4m 35s from start | 5 |
| iridium-147_0 | orbcomm-fm112 | t0 + 293.3s | 5m 9s from start | 6 |
| iridium-147_0 | estrack-new-norcia GS | t0 + 3201.6s | 53m 37s from start | 7 |
| iridium-147_0 | estrack-kiruna GS | t0 + 3201.9s | 53m 36s from start | 8 |
| iridium-147_0 | estrack-malargue GS | t0 + 3202.7s | 53m 37s from start | 9 |
| iridium-147_0 | estrack-santa-maria GS | t0 + 3202.9s | 53m 37s from start | 10 |
| iridium-147_0 | estrack-redu GS | t0 + 3219.3s | 53m 54s from start | 11 |
| iridium-147_0 | estrack-kourou GS | t0 + 3219.4s | 53m 54s from start | 12 |
| iridium-147_0 | estrack-cebreros GS | t0 + 3222.3s | 53m 57s from start | 13 |
| lemur-1_0 | lemur-1 producer | t0 | 11s from start ← t0 | 1 |
| lemur-1_0 | oneweb-0209 | t0 + 99.1s | 1m 51s from start | 2 |
| lemur-1_0 | globalstar-m077 | t0 + 101.2s | 1m 53s from start | 3 |
| lemur-1_0 | oneweb-0548 | t0 + 171.9s | 3m 3s from start | 4 |
| lemur-1_0 | estrack-malargue GS | t0 + 1432.8s | 24m 4s from start | 5 |
| lemur-1_0 | estrack-new-norcia GS | t0 + 1625.1s | 27m 17s from start | 6 |
| lemur-1_0 | estrack-santa-maria GS | t0 + 1625.5s | 27m 17s from start | 7 |
| lemur-1_0 | iridium-147 | t0 + 1975.9s | 33m 7s from start | 8 |
| lemur-2-cael_0 | lemur-2-cael producer | t0 | 12s from start ← t0 | 1 |
| lemur-2-cael_0 | orbcomm-fm112 | t0 + 73.0s | 1m 25s from start | 2 |
| lemur-2-cael_0 | orbcomm-fm06 | t0 + 212.4s | 3m 44s from start | 3 |
| lemur-2-cael_0 | estrack-kourou GS | t0 + 1386.5s | 23m 18s from start | 4 |
| lemur-2-cael_0 | estrack-redu GS | t0 + 1386.6s | 23m 18s from start | 5 |
| lemur-2-cael_0 | estrack-kiruna GS | t0 + 1386.7s | 23m 18s from start | 6 |
| lemur-2-cael_0 | estrack-new-norcia GS | t0 + 1386.8s | 23m 19s from start | 7 |
| lemur-2-cael_0 | estrack-malargue GS | t0 + 1386.9s | 23m 19s from start | 8 |
| lemur-2-cael_0 | estrack-santa-maria GS | t0 + 1387.1s | 23m 19s from start | 9 |
| lemur-2-cael_0 | estrack-cebreros GS | t0 + 1402.1s | 23m 34s from start | 10 |
| lemur-2-deanandmaeve_0 | lemur-2-deanandmaeve producer | t0 | 10s from start ← t0 | 1 |
| lemur-2-deanandmaeve_0 | iridium-136 | t0 + 94.5s | 1m 45s from start | 2 |
| lemur-2-deanandmaeve_0 | estrack-kiruna GS | t0 + 1590.5s | 26m 41s from start | 3 |
| lemur-2-deanandmaeve_0 | estrack-kourou GS | t0 + 1590.8s | 26m 41s from start | 4 |
| lemur-2-deanandmaeve_0 | estrack-redu GS | t0 + 1590.8s | 26m 41s from start | 5 |
| lemur-2-deanandmaeve_0 | estrack-cebreros GS | t0 + 1591.1s | 26m 41s from start | 6 |
| lemur-2-deanandmaeve_0 | estrack-malargue GS | t0 + 1592.0s | 26m 42s from start | 7 |
| lemur-2-deanandmaeve_0 | estrack-santa-maria GS | t0 + 1592.3s | 26m 43s from start | 8 |
| lemur-2-deanandmaeve_0 | estrack-new-norcia GS | t0 + 1627.1s | 27m 17s from start | 9 |
| lemur-2-marache-fran_0 | lemur-2-marache-fran producer | t0 | 14s from start ← t0 | 1 |
| lemur-2-marache-fran_0 | iridium-106 | t0 + 36.5s | 51s from start | 2 |
| lemur-2-marache-fran_0 | orbcomm-fm112 | t0 + 88.6s | 1m 43s from start | 3 |
| lemur-2-marache-fran_0 | flock-4be-23 | t0 + 92.6s | 1m 47s from start | 4 |
| lemur-2-marache-fran_0 | estrack-new-norcia GS | t0 + 3207.0s | 53m 41s from start | 5 |
| lemur-2-marache-fran_0 | estrack-redu GS | t0 + 3207.3s | 53m 41s from start | 6 |
| lemur-2-marache-fran_0 | estrack-kourou GS | t0 + 3207.8s | 53m 41s from start | 7 |
| lemur-2-marache-fran_0 | estrack-malargue GS | t0 + 3208.7s | 53m 42s from start | 8 |
| lemur-2-marache-fran_0 | estrack-santa-maria GS | t0 + 3208.9s | 53m 42s from start | 9 |
| lemur-2-marache-fran_0 | estrack-cebreros GS | t0 + 3210.8s | 53m 44s from start | 10 |
| oneweb-0012_0 | oneweb-0012 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0012_0 | flock-4g-36 | t0 + 75.0s | 1m 27s from start | 2 |
| oneweb-0012_0 | skysat-c12 | t0 + 77.3s | 1m 30s from start | 3 |
| oneweb-0012_0 | flock-4h-14 | t0 + 82.8s | 1m 35s from start | 4 |
| oneweb-0012_0 | globalstar-m077 | t0 + 83.1s | 1m 35s from start | 5 |
| oneweb-0012_0 | oneweb-0519 | t0 + 109.6s | 2m 2s from start | 6 |
| oneweb-0012_0 | oneweb-0334 | t0 + 133.4s | 2m 26s from start | 7 |
| oneweb-0012_0 | estrack-santa-maria GS | t0 + 1592.1s | 26m 44s from start | 8 |
| oneweb-0012_0 | estrack-kourou GS | t0 + 1594.1s | 26m 46s from start | 9 |
| oneweb-0012_0 | estrack-new-norcia GS | t0 + 1594.3s | 26m 47s from start | 10 |
| oneweb-0012_0 | estrack-cebreros GS | t0 + 1594.3s | 26m 47s from start | 11 |
| oneweb-0012_0 | estrack-redu GS | t0 + 1594.4s | 26m 47s from start | 12 |
| oneweb-0012_0 | estrack-malargue GS | t0 + 1594.5s | 26m 47s from start | 13 |
| oneweb-0012_0 | estrack-kiruna GS | t0 + 1595.0s | 26m 47s from start | 14 |
| oneweb-0209_0 | oneweb-0209 producer | t0 | 13s from start ← t0 | 1 |
| oneweb-0209_0 | globalstar-m077 | t0 + 61.1s | 1m 14s from start | 2 |
| oneweb-0209_0 | lemur-1 | t0 + 66.6s | 1m 20s from start | 3 |
| oneweb-0209_0 | iridium-147 | t0 + 2156.2s | 36m 9s from start | 4 |
| oneweb-0334_0 | oneweb-0334 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0334_0 | oneweb-0519 | t0 + 52.6s | 1m 5s from start | 2 |
| oneweb-0334_0 | oneweb-0012 | t0 + 151.2s | 2m 44s from start | 3 |
| oneweb-0334_0 | flock-4g-36 | t0 + 154.3s | 2m 47s from start | 4 |
| oneweb-0334_0 | flock-4h-14 | t0 + 155.9s | 2m 48s from start | 5 |
| oneweb-0334_0 | globalstar-m082 | t0 + 304.9s | 5m 17s from start | 6 |
| oneweb-0334_0 | estrack-santa-maria GS | t0 + 1632.3s | 27m 25s from start | 7 |
| oneweb-0334_0 | estrack-malargue GS | t0 + 2131.6s | 35m 44s from start | 8 |
| oneweb-0334_0 | estrack-new-norcia GS | t0 + 2143.2s | 35m 56s from start | 9 |
| oneweb-0334_0 | estrack-kiruna GS | t0 + 2165.4s | 36m 18s from start | 10 |
| oneweb-0334_0 | estrack-redu GS | t0 + 3213.8s | 53m 45s from start | 11 |
| oneweb-0334_0 | estrack-kourou GS | t0 + 3213.8s | 53m 45s from start | 12 |
| oneweb-0334_0 | estrack-cebreros GS | t0 + 3217.5s | 53m 49s from start | 13 |
| oneweb-0519_0 | oneweb-0519 producer | t0 | 11s from start ← t0 | 1 |
| oneweb-0519_0 | oneweb-0334 | t0 + 58.4s | 1m 10s from start | 2 |
| oneweb-0519_0 | oneweb-0012 | t0 + 85.6s | 1m 37s from start | 3 |
| oneweb-0519_0 | flock-4g-36 | t0 + 86.2s | 1m 38s from start | 4 |
| oneweb-0519_0 | flock-4h-14 | t0 + 106.2s | 1m 58s from start | 5 |
| oneweb-0519_0 | estrack-santa-maria GS | t0 + 1376.9s | 23m 8s from start | 6 |
| oneweb-0519_0 | estrack-cebreros GS | t0 + 1378.2s | 23m 9s from start | 7 |
| oneweb-0519_0 | estrack-kourou GS | t0 + 1378.3s | 23m 10s from start | 8 |
| oneweb-0519_0 | estrack-kiruna GS | t0 + 1378.4s | 23m 10s from start | 9 |
| oneweb-0519_0 | estrack-new-norcia GS | t0 + 1378.4s | 23m 10s from start | 10 |
| oneweb-0519_0 | estrack-malargue GS | t0 + 1379.0s | 23m 10s from start | 11 |
| oneweb-0548_0 | oneweb-0548 producer | t0 | 11s from start ← t0 | 1 |
| oneweb-0548_0 | iridium-136 | t0 + 29.8s | 41s from start | 2 |
| oneweb-0548_0 | flock-4g-7 | t0 + 84.1s | 1m 35s from start | 3 |
| oneweb-0548_0 | iridium-147 | t0 + 92.9s | 1m 44s from start | 4 |
| oneweb-0548_0 | lemur-2-deanandmaeve | t0 + 110.2s | 2m 2s from start | 5 |
| oneweb-0548_0 | lemur-1 | t0 + 269.4s | 4m 41s from start | 6 |
| oneweb-0548_0 | estrack-kiruna GS | t0 + 1396.8s | 23m 28s from start | 7 |
| oneweb-0548_0 | estrack-kourou GS | t0 + 1396.9s | 23m 28s from start | 8 |
| oneweb-0548_0 | estrack-new-norcia GS | t0 + 1397.0s | 23m 28s from start | 9 |
| oneweb-0548_0 | estrack-redu GS | t0 + 1397.1s | 23m 28s from start | 10 |
| oneweb-0548_0 | estrack-malargue GS | t0 + 1397.4s | 23m 29s from start | 11 |
| oneweb-0548_0 | estrack-santa-maria GS | t0 + 1397.5s | 23m 29s from start | 12 |
| oneweb-0548_0 | estrack-cebreros GS | t0 + 1408.5s | 23m 40s from start | 13 |
| orbcomm-fm06_0 | orbcomm-fm06 producer | t0 | 11s from start ← t0 | 1 |
| orbcomm-fm06_0 | flock-4g-36 | t0 + 174.4s | 3m 5s from start | 2 |
| orbcomm-fm06_0 | skysat-c12 | t0 + 180.1s | 3m 11s from start | 3 |
| orbcomm-fm06_0 | lemur-2-cael | t0 + 212.2s | 3m 43s from start | 4 |
| orbcomm-fm06_0 | globalstar-m077 | t0 + 225.3s | 3m 56s from start | 5 |
| orbcomm-fm06_0 | estrack-malargue GS | t0 + 241.6s | 4m 12s from start | 6 |
| orbcomm-fm06_0 | estrack-cebreros GS | t0 + 244.0s | 4m 15s from start | 7 |
| orbcomm-fm06_0 | estrack-redu GS | t0 + 244.0s | 4m 15s from start | 8 |
| orbcomm-fm06_0 | estrack-new-norcia GS | t0 + 244.0s | 4m 15s from start | 9 |
| orbcomm-fm06_0 | estrack-santa-maria GS | t0 + 244.2s | 4m 15s from start | 10 |
| orbcomm-fm06_0 | estrack-kiruna GS | t0 + 244.3s | 4m 15s from start | 11 |
| orbcomm-fm06_0 | globalstar-m082 | t0 + 313.8s | 5m 25s from start | 12 |
| orbcomm-fm112_0 | orbcomm-fm112 producer | t0 | 15s from start ← t0 | 1 |
| orbcomm-fm112_0 | lemur-2-cael | t0 + 66.7s | 1m 22s from start | 2 |
| orbcomm-fm112_0 | flock-4be-23 | t0 + 133.9s | 2m 29s from start | 3 |
| orbcomm-fm112_0 | lemur-2-marache-fran | t0 + 137.1s | 2m 32s from start | 4 |
| orbcomm-fm112_0 | iridium-147 | t0 + 293.9s | 5m 9s from start | 5 |
| orbcomm-fm112_0 | estrack-new-norcia GS | t0 + 2447.5s | 41m 3s from start | 6 |
| orbcomm-fm112_0 | estrack-kiruna GS | t0 + 2447.6s | 41m 3s from start | 7 |
| orbcomm-fm112_0 | estrack-malargue GS | t0 + 2448.4s | 41m 3s from start | 8 |
| orbcomm-fm112_0 | estrack-santa-maria GS | t0 + 2448.8s | 41m 4s from start | 9 |
| orbcomm-fm112_0 | estrack-redu GS | t0 + 3217.1s | 53m 51s from start | 10 |
| orbcomm-fm112_0 | estrack-kourou GS | t0 + 3218.0s | 53m 52s from start | 11 |
| orbcomm-fm112_0 | estrack-cebreros GS | t0 + 3221.0s | 53m 55s from start | 12 |
| skysat-c12_0 | skysat-c12 producer | t0 | 13s from start ← t0 | 1 |
| skysat-c12_0 | flock-4h-14 | t0 + 65.6s | 1m 19s from start | 2 |
| skysat-c12_0 | oneweb-0012 | t0 + 75.5s | 1m 29s from start | 3 |
| skysat-c12_0 | flock-4g-36 | t0 + 117.6s | 2m 11s from start | 4 |
| skysat-c12_0 | globalstar-m077 | t0 + 169.6s | 3m 3s from start | 5 |
| skysat-c12_0 | orbcomm-fm06 | t0 + 174.6s | 3m 8s from start | 6 |
| skysat-c12_0 | estrack-santa-maria GS | t0 + 1595.8s | 26m 49s from start | 7 |
| skysat-c12_0 | estrack-kiruna GS | t0 + 1597.2s | 26m 50s from start | 8 |
| skysat-c12_0 | estrack-cebreros GS | t0 + 1597.3s | 26m 51s from start | 9 |
| skysat-c12_0 | estrack-malargue GS | t0 + 1599.5s | 26m 53s from start | 10 |
| skysat-c12_0 | estrack-new-norcia GS | t0 + 1626.2s | 27m 19s from start | 11 |
| skysat-c12_0 | estrack-redu GS | t0 + 2120.1s | 35m 33s from start | 12 |
| skysat-c12_0 | estrack-kourou GS | t0 + 2120.5s | 35m 34s from start | 13 |
Charts
charts/network_tx.png
gnuplot/delivery.png
Files
- Kubernetes resources — manifests to reproduce this run (hardwaredefinitions, layout, experimentdefinition, experiment)
- metrics.json — KPIs as JSON
- raw-parquet.tar — raw metrics & events as typed, zstd-compressed Parquet (one file per series; read with pandas/polars/DuckDB)
