YASS results
/ uc2nr / uc2nr-edfs-pdefault-n08-rf1
uc2nr-edfs-pdefault-n08-rf1
edfs
Failed
Parameters
| parameter | value | unit | description |
|---|---|---|---|
| engine | edfs | — | Storage/transport engine under test (edfs or tus) |
| priority | default | — | File priority class (low/default/high; EDFS PAR) |
| sat_count | 8 | sats | Number of satellites in the constellation |
| RF | 1 | copies | EDFS replication factor (n/a for TUS) |
KPIs
| KPI | value | unit | description |
|---|---|---|---|
| state | Success | — | Terminal experiment state (Success/TimedOut/Failure) |
| exec_date | 2026-06-10 19:46 UTC | UTC | Wall-clock date/time the experiment was launched (CR creationTimestamp) |
| duration | 30m 21s | — | Experiment duration on the simulation clock (simulationStartTime → experimentTime) |
| sim_start | 2026-05-16 23:59 UTC | UTC | Simulation clock at experiment start (simulationStartTime) |
| sim_end | 2026-05-17 00:29 UTC | UTC | Simulation clock when the experiment finished (experimentTime) |
| produced | 8 | files | Files produced by the producer agent(s) |
| files_to_GS | 7 | count | Distinct produced files that reached at least one ground station |
| delivery_success_rate | 88 | % | Distinct files reaching ≥1 GS as a percentage of files produced (UC2/UC5 primary KPI) |
| all_delivered | no | — | Whether every produced file reached a ground station |
| first_GS_delivery_s | 121 | s | Time from sim start until the first produced file reached any ground station |
| last_GS_delivery_s | 1819 | s | Time from sim start until the last produced file reached a ground station (all-delivered time) |
| GS_reached | 7 | count | Ground stations that received the file (from received_total — independent of the delivery-time metric) |
| distinct_receivers | 15 | count | Distinct nodes that received a file (GS + relays) |
| TX_MiB | 3938 | MiB | Total network bytes transmitted, all nodes |
| peak_cpu_m | 510 | millicores | Peak CPU across all containers |
| peak_mem_MiB | 220 | MiB | Peak memory across all containers |
| notes | 1 of 8 file(s) undelivered | — | Data-quality flags for this run (missing metrics, undelivered files) |
Charts (interactive)
Node colours are consistent across every chart and the graph: ■ ground station · ■ relay satellite · ■ producer.
Per-target delivery time
Seconds from file creation until each target node held the complete file. Bars coloured by node kind; the delivery KPI is the earliest ground-station bar.
Network TX over time (MiB)
Cumulative TX summed across all nodes, vs seconds from experiment start.
CPU and memory over time
Aggregate CPU (millicores, left axis) and memory (MiB, right axis) across all containers, vs seconds from experiment start.
Network TX by node (top 20)
Total bytes transmitted per node over the run, coloured by node kind.
Peak CPU per node (top 20)
Peak CPU (millicores) reached by each fsNode during the run, coloured by node kind.
Peak memory per node (top 20)
Peak memory (MiB) reached by each fsNode during the run, coloured by node kind.
File propagation graph
■ ground station · ● relay satellite · ● producer (same colours as the charts). Spread tree: one edge
from → to per node = where it first acquired the file by the selected time. Grouped per file; 0-byte control messages omitted; times bucketed to ~2 s for cross-node clock skew. Timeline spans the whole experiment (0 = simulation start). Delivery completeness is the File deliveries table below. File transfer graph (rate)
Same nodes; edge
from → to = bytes transferred within the trailing window ending at the selected time (instantaneous flow). Edge colour = bandwidth (bits/s, blue = low → red = high); label shows the rate. Play to watch where traffic moves moment-to-moment. Timeline is the simulation clock (0 = simulation start), shared with the charts above.File deliveries
| file | received by | delivery (s from creation) | time from start | #fsNodes with file |
|---|---|---|---|---|
| flock-4be-17_0 | flock-4be-17 producer | t0 | 11s from start ← t0 | 1 |
| flock-4be-17_0 | oneweb-0614 | t0 + 126.2s | 2m 17s from start | 2 |
| flock-4be-17_0 | estrack-kourou GS | t0 + 1634.7s | 27m 26s from start | 3 |
| flock-4be-17_0 | estrack-new-norcia GS | t0 + 1634.7s | 27m 26s from start | 4 |
| flock-4be-17_0 | estrack-cebreros GS | t0 + 1634.7s | 27m 26s from start | 5 |
| flock-4be-17_0 | estrack-kiruna GS | t0 + 1634.9s | 27m 26s from start | 6 |
| flock-4be-17_0 | estrack-redu GS | t0 + 1635.2s | 27m 26s from start | 7 |
| flock-4be-17_0 | estrack-malargue GS | t0 + 1635.3s | 27m 27s from start | 8 |
| flock-4be-17_0 | estrack-santa-maria GS | t0 + 1651.0s | 27m 42s from start | 9 |
| flock-4h-9_0 | flock-4h-9 producer | t0 | 11s from start ← t0 | 1 |
| flock-4h-9_0 | orbcomm-fm06 | t0 + 99.3s | 1m 51s from start | 2 |
| flock-4h-9_0 | oneweb-0614 | t0 + 177.2s | 3m 9s from start | 3 |
| flock-4h-9_0 | estrack-cebreros GS | t0 + 1665.1s | 27m 57s from start | 4 |
| flock-4h-9_0 | estrack-santa-maria GS | t0 + 1665.2s | 27m 57s from start | 5 |
| flock-4h-9_0 | estrack-redu GS | t0 + 1665.3s | 27m 57s from start | 6 |
| flock-4h-9_0 | estrack-malargue GS | t0 + 1665.3s | 27m 57s from start | 7 |
| flock-4h-9_0 | estrack-kiruna GS | t0 + 1665.4s | 27m 57s from start | 8 |
| flock-4h-9_0 | estrack-new-norcia GS | t0 + 1671.4s | 28m 3s from start | 9 |
| flock-4h-9_0 | estrack-kourou GS | t0 + 1690.5s | 28m 22s from start | 10 |
| globalstar-m081_0 | globalstar-m081 producer | t0 | 11s from start ← t0 | 1 |
| globalstar-m081_0 | orbcomm-fm06 | t0 + 1687.9s | 28m 19s from start | 2 |
| iridium-116_0 | iridium-116 producer | t0 | 12s from start ← t0 | 1 |
| iridium-116_0 | orbcomm-fm06 | t0 + 143.2s | 2m 35s from start | 2 |
| iridium-116_0 | oneweb-0614 | t0 + 194.4s | 3m 26s from start | 3 |
| iridium-116_0 | estrack-redu GS | t0 + 1648.6s | 27m 40s from start | 4 |
| iridium-116_0 | estrack-kiruna GS | t0 + 1648.6s | 27m 40s from start | 5 |
| iridium-116_0 | estrack-cebreros GS | t0 + 1648.9s | 27m 41s from start | 6 |
| iridium-116_0 | estrack-new-norcia GS | t0 + 1649.2s | 27m 41s from start | 7 |
| iridium-116_0 | estrack-santa-maria GS | t0 + 1653.7s | 27m 46s from start | 8 |
| iridium-116_0 | estrack-kourou GS | t0 + 1687.8s | 28m 20s from start | 9 |
| iridium-116_0 | estrack-malargue GS | t0 + 1817.3s | 30m 26s from start | 10 |
| lemur-2-squirrelcomm_0 | lemur-2-squirrelcomm producer | t0 | 12s from start ← t0 | 1 |
| lemur-2-squirrelcomm_0 | oneweb-0173 | t0 + 80.1s | 1m 32s from start | 2 |
| lemur-2-squirrelcomm_0 | estrack-santa-maria GS | t0 + 1819.2s | 30m 27s from start | 3 |
| lemur-2-squirrelcomm_0 | estrack-malargue GS | t0 + 1819.5s | 30m 28s from start | 4 |
| lemur-2-squirrelcomm_0 | estrack-kiruna GS | t0 + 1819.5s | 30m 28s from start | 5 |
| lemur-2-squirrelcomm_0 | estrack-redu GS | t0 + 1819.6s | 30m 28s from start | 6 |
| lemur-2-squirrelcomm_0 | estrack-cebreros GS | t0 + 1819.9s | 30m 28s from start | 7 |
| lemur-2-squirrelcomm_0 | estrack-kourou GS | t0 + 1820.1s | 30m 28s from start | 8 |
| lemur-2-squirrelcomm_0 | estrack-new-norcia GS | t0 + 1820.3s | 30m 28s from start | 9 |
| oneweb-0173_0 | oneweb-0173 producer | t0 | 11s from start ← t0 | 1 |
| oneweb-0173_0 | lemur-2-squirrelcomm | t0 + 80.2s | 1m 31s from start | 2 |
| oneweb-0173_0 | estrack-santa-maria GS | t0 + 1813.7s | 30m 21s from start | 3 |
| oneweb-0173_0 | estrack-malargue GS | t0 + 1814.0s | 30m 22s from start | 4 |
| oneweb-0173_0 | estrack-redu GS | t0 + 1814.1s | 30m 22s from start | 5 |
| oneweb-0173_0 | estrack-kiruna GS | t0 + 1814.1s | 30m 22s from start | 6 |
| oneweb-0173_0 | estrack-cebreros GS | t0 + 1814.1s | 30m 22s from start | 7 |
| oneweb-0173_0 | estrack-new-norcia GS | t0 + 1814.3s | 30m 22s from start | 8 |
| oneweb-0173_0 | estrack-kourou GS | t0 + 1814.5s | 30m 22s from start | 9 |
| oneweb-0614_0 | oneweb-0614 producer | t0 | 12s from start ← t0 | 1 |
| oneweb-0614_0 | flock-4h-9 | t0 + 83.3s | 1m 35s from start | 2 |
| oneweb-0614_0 | iridium-116 | t0 + 101.3s | 1m 53s from start | 3 |
| oneweb-0614_0 | orbcomm-fm06 | t0 + 113.3s | 2m 5s from start | 4 |
| oneweb-0614_0 | flock-4be-17 | t0 + 156.4s | 2m 48s from start | 5 |
| oneweb-0614_0 | globalstar-m081 | t0 + 1668.2s | 28m 0s from start | 6 |
| oneweb-0614_0 | estrack-new-norcia GS | t0 + 1710.8s | 28m 42s from start | 7 |
| oneweb-0614_0 | estrack-santa-maria GS | t0 + 1714.3s | 28m 46s from start | 8 |
| oneweb-0614_0 | estrack-kourou GS | t0 + 1714.7s | 28m 46s from start | 9 |
| oneweb-0614_0 | estrack-cebreros GS | t0 + 1714.8s | 28m 46s from start | 10 |
| oneweb-0614_0 | estrack-kiruna GS | t0 + 1714.9s | 28m 47s from start | 11 |
| oneweb-0614_0 | estrack-redu GS | t0 + 1715.1s | 28m 47s from start | 12 |
| oneweb-0614_0 | estrack-malargue GS | t0 + 1715.1s | 28m 47s from start | 13 |
| orbcomm-fm06_0 | orbcomm-fm06 producer | t0 | 11s from start ← t0 | 1 |
| orbcomm-fm06_0 | flock-4h-9 | t0 + 101.7s | 1m 53s from start | 2 |
| orbcomm-fm06_0 | oneweb-0614 | t0 + 110.8s | 2m 2s from start | 3 |
| orbcomm-fm06_0 | estrack-malargue GS | t0 + 120.9s | 2m 12s from start | 4 |
| orbcomm-fm06_0 | estrack-cebreros GS | t0 + 121.1s | 2m 12s from start | 5 |
| orbcomm-fm06_0 | estrack-kourou GS | t0 + 121.2s | 2m 12s from start | 6 |
| orbcomm-fm06_0 | estrack-kiruna GS | t0 + 121.2s | 2m 12s from start | 7 |
| orbcomm-fm06_0 | estrack-santa-maria GS | t0 + 121.3s | 2m 12s from start | 8 |
| orbcomm-fm06_0 | estrack-redu GS | t0 + 121.4s | 2m 12s from start | 9 |
| orbcomm-fm06_0 | estrack-new-norcia GS | t0 + 121.4s | 2m 12s from start | 10 |
Charts
charts/network_tx.png
gnuplot/delivery.png
Files
- Kubernetes resources — manifests to reproduce this run (hardwaredefinitions, layout, experimentdefinition, experiment)
- metrics.json — KPIs as JSON
- raw-parquet.tar — raw metrics & events as typed, zstd-compressed Parquet (one file per series; read with pandas/polars/DuckDB)
